CB Type Axial Flow Pump

ZLB and ZLG pumps are single-stage vertical axial flow pumps, while ZWB and ZXB pumps are extra-large horizontal and oblique axial flow pumps, suitable for pumping clean water, sewage, rainwater and slightly corrosive liquids, with the temperature of the transported liquid not exceeding 50°C. This type of pump is a large-flow, low-lift pump, suitable for farmland irrigation and drainage, water conservancy projects, urban water supply, drainage and sewage treatment, power plants, salt plants and farms to transport circulating water, dock water level raising and lowering, and can also be used in metallurgy, chemical industry and other industries, and is widely used.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.

For vertical axial flow pumps, the pump and motor are installed on two foundation layers respectively. The axial thrust of the pump is borne by the motor. The pump bearing is a rubber guide bearing and the seal is a packing seal.
For horizontal (oblique) axial flow pumps, the entire pump system consists of hydraulic flow channel, pump body, transmission, motor and auxiliary equipment. The transmission part is a gear reducer.

If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

coming soon

coming soon

General Specifications of Axial Flow Pump Series

Flow range: 0.5~60 m³/h
Head range: 2.0~15 m

Axial Flow Pump Model Description

  • 80ZLB-5
  • 80-discharge diameter of a pump (i.e. 2000/25=80)
  • Z-axial flow pump
  • L-vertical
  • B-semi-adjustable blades (G is fixed blades)
  • 5-design point head of a pump
  • 120ZWB-3
  • 120-pump impeller diameter (120X25=3000)
  • Z-axial flow pump
  • W-horizontal
  • B-semi-adjustable blades (G is fixed blades)
  • 3-design point head of a pump

Click Kit Name to Check Part List

Pump Performance Data Sheet

ParameterType

Capacity
Q
Head
H
Speed
n
Shaft power
Pa
Motor  Eff.
η
impolier
Dia
Outlet Dia Weight Angle
power Type
m³/h m r/min kW kW % mm mm t ()°
8.75 8 290 797.6 YL800-20/1730 86.1 1600
64ZLG-6 10.00 6 290 688.9 800 88 1480 18 0
11.00 3.87 290 499.5 83.6
12.50 5.91 250 842.7 YKSL900-24/2150 86 2000
80ZLB-5 13.30 4.85 250 727 900 87 1860 23.5 0
16.10 2.85 250 555.7 81
26.00 3.06 115.9 883.9 T1250-8/1180 88.3 3150 -8
120ZWB-3 36.00 3 115.9 1190.4 1250 89 3000 48 0
42.00 2.65 115.9 1307.6 83.5 4
36.00 3 122 1204 YD710-6/8

2361X

5000

-4
132ZXB-3 45.50 2.6 122 1319 2000 88 3250 65.3 0
48.00 2.9 122 1551.8 2
26.00 1.8 92 527.7 YD710-6/8 N/A -4
132ZXB-3 34.10 1.45 92 557.5 1000 87 3250 65.3 0
36.00 1.62 92 657.6 2
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
