CB Type DG(Steam) Boiler Feed Pump

DG (Steam) industrial steam boiler feed pump is a single-suction, multi-stage segmental centrifugal pump; this series of pumps is a high-efficiency and energy-saving product specially designed for the new series of industrial steam boilers to be updated and renovated. It is not only suitable for medium and low pressure boiler feed water, but also for high-lift water delivery in factories and cities. The medium temperature is -20 ℃~105 ℃, and the pump inlet pressure shall not exceed 0.59 MPa (6 kgf/cm²).

The suction and discharge ports of DG (Steam) pumps are both vertically upward, the pump rotor is supported by rolling bearings, grease lubrication, and the axial thrust balance adopts a balance disc structure. The shaft seal can be a packing seal or a mechanical seal.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.

If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

Ebara XBD-FS Fire Pump Video

coming soon

coming soon

coming soon

General Specifications of DG (Steam) Series

Flow range: 1.5~78 m³/h
Head range: 73~405 m

DG (Steam) Model Description

  • DG5-27×3
  • DG single suction, multi-stage boiler feed pump
  • 5-flow rate (m³/h)
  • 27-pump single-stage head (m)
  • 3-number of pump stages

Click Kit Name to Check Part List

ParameterType

 Capacity
Q		 Head
H		 Speed
N		 Shaft power
Pa		 Motor  Eff.
η		 NPSH
r		 impolier
Dia		 Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
DG5-27×3 3
5
8		 0.83
1.39
2.22		 84
81
75		 2980 3.1
3.45
4.08		 7.5 Y132S₂-2 22
32
40		 2.8 150 40 32 175
DG5-27×4 3
5
8		 0.83
1.39
2.22		 112
108
100		 2980 4.14
4.6
5.44		 7.5 Y132S₂-2 22
32
40		 2.8 150 40 32 185
DG5-27×5 3
5
8		 0.83
1.39
2.22		 140
135
125		 2980 5.17
5.75
6.8		 11 Y160M₁-2 22
32
40		 2.8 150 40 32 195
DG5-27×6 3
5
8		 0.83
1.39
2.22		 168
162
150		 2980 6.21
6.9
8.16		 11 Y160M₁-2 22
32
40		 2.8 150 40 32 205
DG5-27×7 3
5
8		 0.83
1.39
2.22		 196
189
175		 2980 7.25
8.05
9.5		 11 Y160M₁-2 22
32
40		 2.8 150 40 32 215
DG5-27×8 3
5
8		 0.83
1.39
2.22		 224
216
200		 2980 8.29
9.2
10.88		 15 Y160M₂-2 22
32
40		 2.8 150 40 32 225
DG5-27×9 3
5
8		 0.83
1.39
2.22		 252
243
225		 2980 9.32
10.35
12.25		 15 Y160M₂-2 22
32
40		 2.8 150 40 32 235
DG5-27×10 3
5
8		 0.83
1.39
2.22		 280
270
250		 2980 10.36
11.5
13.6		 15 Y160M₂-2 22
32
40		 2.8 150 40 32 245
DG5-27×11 3
5
8		 0.83
1.39
2.22		 308
297
275		 2980 11.39
12.65
14.96		 18.5 Y160L-2 22
32
40		 2.8 150 40 32 255
DG5-27×12 3
5
8		 0.83
1.39
2.22		 336
324
300		 2980 12.43
13.8
16.32		 18.5 Y160L-2 22
32
40		 2.8 150 40 32 265
DG8-35×3 5
8
10		 1.39
2.22
2.78		 109
99
85		 2980 4.79
5.99
6.44		 11 Y160M₁-2 31
36
36		 3.6
3.7
4.6		 170 40 40 144.1
DG8-35×4 5
8
10		 1.39
2.22
2.78		 146
132
114		 2980 6.42
7.98
8.63		 11 Y160M₁-2 31
36
36		 3.6
3.7
4.6		 170 40 40 156.5
DG8-35×5 5
8
10		 1.39
2.22
2.78		 182
165
142		 2980 8
9.98
10.75		 15 Y160M₂-2 31
36
36		 3.6
3.7
4.6		 170 40 40 168.9
DG8-35×6 5
8
10		 1.39
2.22
2.78		 218
198
171		 2980 9.58
11.97
12.95		 15 Y160M₂-2 31
36
36		 3.6
3.7
4.6		 170 40 40 181.2
DG8-35×7 5
8
10		 1.39
2.22
2.78		 255
231
199		 2980 11.21
13.97
15.07		 18.5 Y160L-2 31
36
36		 3.6
3.7
4.6		 170 40 40 193.6
DG8-35×8 5
8
10		 1.39
2.22
2.78		 291
264
227		 2980 12.79
15.96
17.19		 22 Y180M-2 31
36
36		 3.6
3.7
4.6		 170 40 40 206
DG8-35×9 5
8
10		 1.39
2.22
2.78		 328
297
256		 2980 16′
17.96
19.38		 22 Y180M-2 31
36
36		 3.6
3.7
4.6		 170 40 40 218.4
DG8-35×10 5
8
10		 1.39
2.22
2.78		 364
330
284		 2980 16
19.95
21.5		 30 Y200L₁-2 31
36
36		 3.6
3.7
4.6		 170 40 40 230.7
——END——

ParameterType

 Capacity
Q		 Head
H		 Speed
N		 Shaft power
Pa		 Motor  Eff.
η		 NPSH
r		 impolier
Dia		 Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
DG13-35×3 10
13
17		 2.7
3.61
4.72		 111
105
87		 2980 7.2
8.3
8.95		 11 Y160M₁-2 42
45
45		 2.2
2.4
2.5		 170 50 50 228
DG13-35×4 10
13
17		 2.7
3.61
4.72		 148
140
116		 2980 9.32
11
11.93		 15 Y160M₂-2 42
45
45		 2.2
2.4
2.5		 170 50 50 250
DG13-35×5 10
13
17		 2.7
3.61
4.72		 185
175
145		 2980 11.66
13.76
14.91		 18.5 Y160L-2 42
45
45		 2.2
2.4
2.5		 170 50 50 272
DG13-35×6 10
13
17		 2.7
3.61
4.72		 222
210
174		 2980 14
16.52
17.89		 22 Y180M-2 42
45
45		 2.2
2.4
2.5		 170 50 50 294
DG13-35×7 10
13
17		 2.7
3.61
4.72		 259
245
203		 2980 16.32
19.27
20.88		 30 Y200L₁-2 42
45
45		 2.2
2.4
2.5		 170 50 50 316
DG13-35×8 10
13
17		 2.7
3.61
4.72		 296
280
230		 2980 18.66
22.02
23.65		 30 Y200L₁-2 42
45
45		 2.2
2.4
2.5		 170 50 50 338
DG13-35×9 10
13
17		 2.7
3.61
4.72		 333
315
261		 2980 20.99
24.77
26.84		 30 Y200L₁-2 42
45
45		 2.2
2.4
2.5		 170 50 50 360
DG13-35×10 10
13
17		 2.7
3.61
4.72		 370
350
290		 2980 23.22
27.53
29.83		 37 Y200L₂-2 42
45
45		 2.2
2.4
2.5		 170 50 50 382
——END——

ParameterType

 Capacity
Q		 Head
H		 Speed
N		 Shaft power
Pa		 Motor  Eff.
η		 NPSH
r		 impolier
Dia		 Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
DG20-35×3 16.3
20
23		 4.53
5.56
6.39		 110
105
100		 2980 8.88
9.87
10.62		 15 Y160M₂-2 55
58
89		 2.8
3
3.3		 165 65 65 197
DG20-35×4 16.3
20
23		 4.53
5.56
6.39		 147
140
134		 2980 11.87
13.16
14.23		 18.5 Y160L-2 55
58
89		 2.8
3
3.3		 165 65 65 210
DG20-35×5 16.3
20
23		 4.53
5.56
6.39		 183
175
167		 2980 14.78
16.45
17.73		 22 Y180M-2 55
58
89		 2.8
3
3.3		 165 65 65 222
DG20-35×6 16.3
20
23		 4.53
5.56
6.39		 220
210
200		 2980 17.76
19.74
21.24		 30 Y200L₁-2 55
58
89		 2.8
3
3.3		 165 65 65 234
DG20-35×7 16.3
20
23		 4.53
5.56
6.39		 256
245
234		 2980 20.67
23.03
24.85		 30 Y200L₁-2 55
58
89		 2.8
3
3.3		 165 65 65 247
DG20-35×8 16.3
20
23		 4.53
5.56
6.39		 293
280
267		 2980 23.66
26.32
28.35		 37 Y200L₂-2 55
58
89		 2.8
3
3.3		 165 65 65 259
DG20-35×9 16.3
20
23		 4.53
5.56
6.39		 330
315
300		 2980 26.65
29.61
31.58		 37 Y200L₂-2 55
58
89		 2.8
3
3.3		 165 65 65 272
DG20-35×10 16.3
20
23		 4.53
5.56
6.39		 366
350
334		 2980 29.55
32.89
35.46		 45 Y225M-2 55
58
89		 2.8
3
3.3		 165 65 65 284
DG25-35×3 20
25
30		 5.56
6.94
8.33		 114
105
93		 2980 10.9
11.71
13.09		 15 Y160M₂-2 57
61
58		 2.7
3
3.3		 175 65 65 243
DG25-35×4 20
25
30		 5.56
6.94
8.33		 152
140
124		 2980 14.54
15.62
17.46		 22 Y180M-2 57
61
58		 2.7
3
3.3		 175 65 65 267
DG25-35×5 20
25
30		 5.56
6.94
8.33		 190
175
155		 2980 18.17
19.52
21.82		 30 Y200L₁-2 57
61
58		 2.7
3
3.3		 175 65 65 291
DG25-35×6 20
25
30		 5.56
6.94
8.33		 228
210
185		 2980 21.8
23.42
26.04		 30 Y200L₁-2 57
61
58		 2.7
3
3.3		 175 65 65 315
DG25-35×7 20
25
30		 5.56
6.94
8.33		 266
245
217		 2980 25.44
28.74
30.55		 37 Y200L₂-2 57
61
58		 2.7
3
3.3		 175 65 65 339
DG25-35×8 20
25
30		 5.56
6.94
8.33		 304
280
248		 2980 29.07
31.23
34.92		 37 Y200L₂-2 57
61
58		 2.7
3
3.3		 175 65 65 363
DG25-35×9 20
25
30		 5.56
6.94
8.33		 342
315
279		 2980 32.71
35.14
39.28		 45 Y225M-2 57
61
58		 2.7
3
3.3		 175 65 65 387
DG25-35×10 20
25
30		 5.56
6.94
8.33		 380
350
310		 2980 36.34
39.04
43.64		 55 Y250M-2 57
61
58		 2.7
3
3.3		 175 65 65 411
——END——

ParameterType

 Capacity
Q		 Head
H		 Speed
N		 Shaft power
Pa		 Motor  Eff.
η		 NPSH
r		 impolier
Dia		 Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
DG42-45×3 25
42
50		 6.94
11.67
13.89		 158
135
120		 2980 20.28
25.74
27.24		 30 Y200L₁-2 53
60
60		 2
2.4
2.8		 275 80 80 201
DG42-45×4 25
42
50		 6.94
11.67
13.89		 210
180
160		 2980 26.96
34.32
36.31		 45 Y225M-2 53
60
60		 2
2.4
2.8		 275 80 80 219
DG42-45×5 25
42
50		 6.94
11.67
13.89		 262
225
200		 2980 33.63
42.9
45.39		 55 Y250M-2 53
60
60		 2
2.4
2.8		 275 80 80 237
DG42-45×6 25
42
50		 6.94
11.67
13.89		 315
270
240		 2980 40.44
51.49
54.47		 75 Y280S-2 53
60
60		 2
2.4
2.8		 275 80 80 254
DG42-45×7 25
42
50		 6.94
11.67
13.89		 368
315
280		 2980 47.24
60
62.54		 75 Y280S-2 53
60
60		 2
2.4
2.8		 275 80 80 272
DG42-45×8 25
42
50		 6.94
11.67
13.89		 420
360
320		 2980 53.91
68.65
72.6		 90 Y280M-2 53
60
60		 2
2.4
2.8		 275 80 80 290
DG42-45×9 25
42
50		 6.94
11.67
13.89		 473
405
360		 2980 60.72
77.23
80.41		 90 Y280M-2 53
60
60		 2
2.4
2.8		 275 80 80 307
DG42-45×10 25
42
50		 6.94
11.67
13.89		 525
450
400		 2980 67.4
85.81
89.35		 110 Y315S-2 53
60
60		 2
2.4
2.8		 275 80 80 325
——END——

ParameterType

 Capacity
Q		 Head
H		 Speed
N		 Shaft power
Pa		 Motor  Eff.
η		 NPSH
r		 impolier
Dia		 Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
DG78-45×3 47
78
90		 13.06
21.67
25		 145
135
127.8		 2980 35.03
41.57
44.12		 55 Y250M-2 53
69
71		 4 195 100 100 242.6
DG78-45×4 47
78
90		 13.06
21.67
25		 194
180
170.4		 2980 46.87
55.42
58.82		 75 Y280S-2 53
69
71		 4 195 100 100 267.8
DG78-45×5 47
78
90		 13.06
21.67
25		 242
225
213		 2980 58.46
69.28
73.53		 90 Y280M-2 53
69
71		 4 195 100 100 293
DG78-45×6 47
78
90		 13.06
21.67
25		 290
270
255.6		 2980 70.06
83.13
88.24		 90 Y280M-2 53
69
71		 4 195 100 100 318.2
DG78-45×7 47
78
90		 13.06
21.67
25		 340
315
298.2		 2980 82.14
97
102.19		 110 Y315S-2 53
69
71		 4 195 100 100 343.4
DG78-45×8 47
78
90		 13.06
21.67
25		 388
360
340.8		 2980 93.73
110.8
117.65		 132 Y315M₁-2 53
69
71		 4 195 100 100 368.6
DG78-45×9 47
78
90		 13.06
21.67
25		 436
405
383.4		 2980 105.3
124.7
132.35		 160 Y315M₂-2 53
69
71		 4 195 100 100 393.8
DG78-45×10 47
78
90		 13.06
21.67
25		 485
450
426		 2980 117.17
138.6
147.1		 160 Y315M₂-2 53
69
71		 4 195 100 100 419
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.

Global Activity

SinoMac Makes Its Mark at Global Maritime Event—A Look Back at Marintec China 2025

Hailed as the"Olympics" of the global maritime industry, Marintec China 2025 took place from December 2 to 5, 2025, at the Shanghai New International Expo Centre. Centered on the theme “Innovation and Cooperation for Sustainable Maritime Development,” this edition showcased cutting-edge technologies, innovative achievements, and sustainable pathways across the global maritime sector. It attracted over 2,000 exhibiting companies and tens of thousands of professional visitors from more than 100 countries and regions, highlighting China's pivotal influence and open-cooperative stance within the global maritime industry.

SinoMac’s Presence at the 2025 Kazakhstan International Mining, Exploration & Coal Processing Exhibition

As one of the most influential mining exhibitions in Central Asia, the Kazakhstan International Mining, Exploration and Coal Processing Exhibition (Mining Week) was grandly held in Karaganda, Kazakhstan from June 24 to 26, 2025. Focused on the entire mining process, this exhibition showcased a concentrated display of technological innovations, equipment upgrades and green solutions-catering to the industry’s full-chain demands and serving as a premier platform for global mining players to showcase technologies, exchange experience and explore partnerships.

Review of SeaMac 2025 Vietnam International Maritime Ship Exhibition:Deeply connecting with the cutting-edge of the global maritime industry

Recently, the highly anticipated 2025 Vietnam International Maritime and Shipbuilding Exhibition concluded successfully at the Adora Convention Center in Ho Chi Minh City. As Vietnam’s largest and most specialized event in shipbuilding and maritime technology, the exhibition gathered top shipbuilders, maritime service providers, and marine equipment manufacturers from around the world. SeaMac actively participated, comprehensively showcasing its innovative achievements and integrated capabilities in ship solutions and high-efficiency propulsion systems. The company engaged in extensive and in-depth exchanges with industry partners, achieving fruitful outcomes from its participation.

Attending a Global Maritime Extravaganza, SinoMac will be showcasing at Marintec China 2025

Attending a Global Maritime Extravaganza, SinoMac will be showcasing at Marintec China 2025

Marintec China 2025, hailed as a "global trendsetter for the maritime industry," will be held from December 2nd to 5th, 2025, at the Shanghai New International Expo Centre. The theme of this year's exhibition is "Innovation and Cooperation for Sustainable Development of the Maritime Industry," and the theme of the High-Level Maritime Forum is "Intelligent Navigation, Green Coexistence, Integration, and Innovation," reflecting expectations for the industry's future.

Review SAUDI RAIL 2025 SinoMac Exhibition Highlights

Review SAUDI RAIL 2025 ：SinoMac Exhibition Highlights

SinoMac successfully participated in SAUDI RAIL 2025, the annual industry event held in Riyadh, Saudi Arabia, from October 19th to 20th, 2025. At the exhibition, SinoMac showcased its strong capabilities in railway technology, innovative solutions, and full lifecycle services, and engaged in in-depth exchanges with industry partners, customers, and experts from around the world to jointly explore future opportunities for rail transit development in the Middle East.

SinoMac-Exhibition-Highlights-Review-1

Deeply Cultivate the International Market, Empowering the Future of Rail ——Focus [PRO//Motion Expo 2025]: SinoMac Exhibition Highlights Review

From August 28 to 31, 2025, the highly anticipated PRO//Motion Expo 2025 (Russian International Railway and Motion Exhibition) grandly opened at the Russian Railway Museum in St. Petersburg. PRO//Motion Expo is currently the largest railway and transportation exhibition in Russia and the Commonwealth of Independent States (CIS), attracting extensive participation from railway companies from CIS countries and around the world. Over the four-day exhibition, exhibitors showcased cutting-edge technologies and innovative achievements in the railway transportation industry.

Focus on marine industry event, start a new chapter of marine development together--SinoGen Power Technology Limited to exhibit at Marine

Focus on marine industry event, start a new chapter of marine development together–SinoGen Power Technology Limited to exhibit at Marine & Offshore Vietnam 2025

Against the backdrop of the booming development of the global shipping and maritime industry, Vietnam International Maritime Expo 2025 (Marine & Offshore Vietnam) will be held in Ho Chi Minh City, Vietnam from 19th to 21st November. As one of the most influential maritime events in Southeast Asia, this exhibition brings together top enterprises and innovations in the fields of global shipbuilding, offshore engineering, port equipment, new energy ship technology, etc., and provides an international platform for industry colleagues to exchange and co-operate and explore the market.

SinoGen Power Technology Limited made its debut at the 2025 Indonesia International Construction Machinery, Mining and Concrete Exhibition

SinoGen Power Technology Limited made its debut at the 2025 Indonesia International Construction Machinery, Mining and Concrete Exhibition

The International Exhibition of Engineering Machinery, Mining, and Concrete (Mining Indonesia) will be held in Jakarta, Indonesia, from September 17 to 20, 2025. As one of the most influential mining exhibitions in Southeast Asia, Mining Indonesia provides a professional platform for enterprises, experts, and practitioners in the global mining sector to showcase cutting-edge technologies, exchange industry insights, and explore collaborative opportunities.

2025 Russian International Railway and Rail Transit Exhibition_ SinoGen invites you to join the industry feast

2025 Russian International Railway and Rail Transit Exhibition: SinoGen invites you to join the industry feast

From August 28 to 31, 2025, the highly anticipated biennial Russian International Railway and Rail Transit Exhibition (PRO/Motion Expo) will be held in St. Petersburg. The exhibition is the largest and most professional railway and transportation exhibition in Eastern Europe and Central Asia. PRO/Motion Expo brings together industry elites, corporate representatives and professional visitors from all over the world to witness the latest development achievements and cutting-edge trends in the railway and rail transit industry. Here, many internationally renowned companies will showcase their latest technologies, products and solutions, covering railway infrastructure construction, train manufacturing, communication and signal systems, intelligent transportation and other fields. From advanced train design and manufacturing technology to efficient railway operation and management solutions; from innovative rail material research and development to intelligent railway communication and control systems, various cutting-edge technologies and innovative achievements will be presented one by one, bringing a wonderful industry feast to the participants.

Sinogen-actively-participated-in-the-International-Railway-and-Rail-Transit-Exhibition-in-Berlin-Germany-to-explore-the-new-future-of-the-industry

Sinogen actively participated in the International Railway and Rail Transit Exhibition in Berlin, Germany, to explore the new future of the industry

From September 22 to 25, 2026, the highly anticipated biennial Berlin International Railway and Rail Transit Exhibition (InnoTrans Berlin) opened grandly in Berlin, Germany. As the largest and most influential event in the global railway and rail transit field, InnoTrans Berlin brings together industry elites, corporate representatives and professional visitors from all over the world to witness the latest development achievements and cutting-edge trends in the railway and rail transit industry. The exhibition covers a number of key areas such as bridges and tunnels, public transportation, and comprehensively displays innovative technologies, advanced equipment and comprehensive solutions in the railway and rail transit industry. From infrastructure construction to operation management, from vehicle manufacturing to intelligent system applications, the exhibition content is rich and diverse, providing participants inside and outside the industry with an excellent platform for a comprehensive understanding of industry dynamics, exchanges and cooperation.

WhatsApp Online logo

Online Service

Sales Director-Mr.Jasper Lee

Sales Manager-Mrs.Wendy Fu

Spare Parts Sales-Miss. Nora Cao

After-Sales Manager-Mr. Jason Zhang

Merchandiser-Miss. Yoyo Tao

Contact EMAC Now!

Subscribe To Our Newsletter

Subscribe to get the latest updates from www.cbpumps.com

Welcome on board, we will keep you updated with latest news and business activities!
