CB Type R Hot water Pump

R-type hot water circulation pump is a single-stage single-suction and two-stage single-suction cantilever centrifugal pump, suitable for metallurgy, power stations, chemical industry and other departments, used to transport high-pressure hot water below 250 ℃ without solid particles. The maximum temperature of the hot water to be transported is 250 ℃, and the maximum inlet pressure of the pump is 5 MPa.

The pump is a single-stage single-suction or two-stage single-suction cantilever type, sealed with a floating ring, and the bearings are rolling bearings and ball bearings, lubricated with thin oil.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.

If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

coming soon

coming soon

General Specifications of R Series

Flow range: 14.4~416 m³/h
Head range: 34~80 m

R Model Description

  • 100R-37A
  • 100-indicates the inlet diameter is 100 mm
  • R-indicates the hot water circulation pump
  • 37-indicates the pump design point head is 37 m
  • A-indicates the impeller outer diameter changes

Click Kit Name to Check Part List

ParameterType

Capacity
Q
Head
H
Speed
N
Shaft power
Pa
Motor  Eff.
η
NPSH
r
impolier
Dia
Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
50R-40×2 14.4 4 80 2980 6.8 11 Y160M1-2 46 4 190 50 40 155
50R-40×2A 13.1 3.6 65 2980 5.3 7.5 Y132S2-2 44 4 172 50 40 155
——END——

ParameterType

Capacity
Q
Head
H
Speed
N
Shaft power
Pa
Motor  Eff.
η
NPSH
r
impolier
Dia
Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
65R-64 28.8 8 64 2980 9.3 11 Y160M1-2 54 4 232 65 50 176
65R-64A 26.9 7.5 55 2980 7.8 11 Y160M1-2 52 4 227 65 50 176
65R-64B 25.3 7 48.5 2980 6.7 7.5 Y132S2-2 50 4 204 65 50 176
65R-40 28.8 8 39.5 2980 5 7.5 Y132S2-2 62 4 182 65 50 165
65R-40A 26.2 7.3 32 2980 3.8 5.5 Y132S1-2 60 4 166 65 50 165
——END——

ParameterType

Capacity
Q
Head
H
Speed
N
Shaft power
Pa
Motor  Eff.
η
NPSH
r
impolier
Dia
Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
80R-38 54 15 38 2980 8.2 11 Y160M1-2 68 4 178 80 65 226
80R-38A 49.1 13.6 30.5 2980 6 7.5 Y132S2-2 68 4 168 80 65 226
——END——

ParameterType

Capacity
Q
Head
H
Speed
N
Shaft power
Pa
Motor  Eff.
η
NPSH
r
impolier
Dia
Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
100R-37 100.8 28 36.5 2980 12.9 18.5 Y160L-2 78 6 180 100 80 240
100R-37A 91.8 25.5 29 2980 9.5 15 Y160M2-2 76 6 167 100 80 240
100R-57 100.8 28 57 2980 21.7 30 Y200M1-2 72 6 225 100 80 250
100R-57A 94.3 26.2 52 2980 19 22 Y180M-2 70 6 215 100 80 250
100R-57B 88.6 24.6 43.5 2980 15.4 22 Y180M-2 68 6 197 100 80 250
——END——

ParameterType

Capacity
Q
Head
H
Speed
N
Shaft power
Pa
Motor  Eff.
η
NPSH
r
impolier
Dia
Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
150R-35 190.8 53 34.7 1480 23.1 30 Y200L-4 78 4 345 150 125 550
150R-35A 173.5 48.2 28 1480 17.4 22 Y180L-4 76 4 310 150 125 550
150R-56 190.8 53 55.5 1480 42.4 55 Y250M-4 68 4 425 150 100 627
150R-56A 178.2 49.5 48 1480 35.3 45 Y225M-4 66 4 397 150 100 627
150R-56B 167.8 46.6 42.5 1480 30.8 37 Y225S-4 63 4 374 150 100 627
——END——

ParameterType

Capacity
Q
Head
H
Speed
N
Shaft power
Pa
Motor  Eff.
η
NPSH
r
impolier
Dia
Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
200R-29 280 77.8 28.5 1480 27.9 45 Y225M-4 78 6 336 200 150 750
200R-29A 250 69.4 22.5 1480 20.2 30 Y200L-4 76 6 299 200 150 750
200R-45 280 77.8 45 1480 44 55 Y250M-4 78 6 405 200 150 830
200R-45A 254 70.6 37 1480 33.7 37 Y225S-4 76 6 375 200 150 830
200R-72 280 77.8 72 1480 78.5 110 Y315S-4 70 6 492 200 150 1025
200R-72A 265 73.5 64 1480 68 75 Y280S-4 68 6 470 200 150 1025
200R-72B 245 68.1 55 1480 54 75 Y280S-4 68 6 200 150 1025
——END——

ParameterType

Capacity
Q
Head
H
Speed
N
Shaft power
Pa
Motor  Eff.
η
NPSH
r
impolier
Dia
Pump diameter weight
power Type Inlet Dia Outlet Dia
m³/h L/s m r/min kW kW % m mm mm mm kg
250R-62 450 125 62 1480 97.5 115 JS114-4 78 6 475 250 200 980
250R-62A 405 112.5 50 1480 72.6 110 Y315S4 76 6 427 250 200 980
250R-40 450 125 39.5 1480 62.1 75 Y280S-4 78 6 378 250 200 850
250R-40A 416 115.6 34 1480 50.7 75 Y280S-4 76 6 355 250 200 850
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
