CB Type ClSL, ClSG,CIW,CIL Marine Pump

CISL, CISG, CIW, CIL single-stage single-suction marine centrifugal pumps are used to transport seawater or fresh water on various ships, and are suitable for cooling systems, circulating water systems, fire fighting systems, and daily water systems of various ships. The inlet pressure of various pump types is 0.6 MPa.

Pump installation form: CISL and CISG are installed vertically, CIL pumps are installed vertically on the sidewall, and CIW pumps are installed horizontally. CISL, CISG, and CIL pumps absorb water horizontally or axially and discharge water horizontally. The CISL pump suction port can be installed in any of four directions: 0°, 90°, 180°, and 270°: the CISG inlet and outlet are on the same horizontal plane; the CIL pump outlet can be installed at several angles: left, right, and forward (backward to the installation surface). Several pump types greatly reduce the footprint and are suitable for use in smaller spaces. CIL, CIW, and CISG pumps are directly connected to the motor, and the impeller is installed on the motor shaft; CISL is connected by a coupling, and the pump uses self-lubricating bearings or oil-containing bearings, without the need for oiling or grease injection. Several pump types use mechanical seals for shaft seals, and are externally flushed with water.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.

If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

General Specifications of ClSL, ClSG,CIW,CIL Series

Flow range:	12.5~400 m³/h
Head range:	20~125 m

ClSL, ClSG,CIW,CIL Model Description

Example: CISL 125-100-200A-Z
C: Marine pump
IS(1): Single-stage single-suction centrifugal pump
L: Vertical installation 125: Inlet diameter (mm)
100: Outlet diameter (mm)
200: Impeller nominal diameter (mm)
A: A, B, C represent the impeller outer diameter after the first, second, and third cuts,
respectively.
Z: indicates that the pump suction port is vertically downward (no Z indicates that the
pump suction port is arranged horizontally)
CISG125-100-200

C: Marine pump
1S(1): Single-stage single-suction centrifugal pump
G: Pipeline installation125: Suction port diameter (mm)
100: Discharge port diameter (mm)
200: Impeller nominal diameter (mm)
CIW125-100-200
C: Marine pump
I: Single-stage single-suction centrifugal pump
W: Horizontal installation125: Suction port diameter (mm)
100: Discharge port diameter (mm)
200: Impeller nominal diameter (mm)

Search by Pump Type

Click Kit Name to Check Part List

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
CISL50-32-125 CISG50-32-125 CIW50-32-125 CIL50-32-125	7.5	2.08	22		0.96			47	2.0
	12.5	3.47	20	2980	1.13	2.2	Y90L-2(V1)	60	2.0	127	50	32	40
	15	4.17	18.5		1.26			60	2.5
CISL50-32-160 CISG50-32-160 CIW50-32-160 CIL50-32-160	7.5	2.08	34.3		1.59			44	2.0
	12.5	3.47	32	2980	2.02	3	Y100L-2(V1)	54	2.0	154	50	32	40
	15	4.17	29.6		2.16			56	2.5
CISL50-32-200 CISG50-32-200 CIW50-32-200 CIL50-32-200	7.5	2.08	52.5		2.82			38	2.0
	12.5	3.47	50	2980	3.55	5.5	Y132S1-2(V1)	48	2.0	198	50	32	43
	15	4.17	48		3.84			51	2.5
CISL50-32-250 CISG50-32-250 CIW50-32-250 CIL50-32-250	7.5	2.08	82		5.88			28.5	2.0
	12.5	3.47	80	2980	7.17	11	Y160M1-2(V1)	38	2.0	243	50	32	76
	15	4.17	78.5		7.82			41	2.5
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
CISL65-50-125 CISG65-50-125 CIW65-50-125 CIL65-50-125	15	4.17	21.8		1.54			58	2
	25	6.94	20	2980	1.97	3	Y100L-2(V1)	69	2.5	126	65	50	38.6
	30	8.33	18.5		2.22			68	3
CISL65-50-160 CISG65-50-160 CIW65-50-160 CIL65-50-160	15	4.17	35		2.5			54	2
	25	6.94	32	2980	3.35	5.5	Y132S1-2(V1)	65	2	161	65	50	39
	30	8.33	30		3.71			66	2.5
CISL65-40-200 CISG65-40-200 CIW65-40-200 CIL65-40-200	15	4.17	53		4.42			49	2
	25	6.94	50	2980	5.67	7.5	Y132S2-2(V1)	60	2	195	65	40	46
	30	8.33	47		6.29			61	2.5
CISL65-40-250 CISG65-40-250 CIW65-40-250 CIL65-40-250	15	4.17	82		9.05			37	2
	25	6.94	80	2980	10.89	15	Y160M2-2(V1)	50	2	247	65	40	80
	30	8.33	78		12.02			53	2.5
CISL65-40-315 CISG65-40-315 CIW65-40-315 CIL65-40-315	15	4.17	127		18.5			28	2.5
	25	6.94	125	2980	21.3	30	Y200L1-2(V1)	40	2.5	307	65	40	106
	30	8.33	123		22.8			44	3
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
CISL80-65-125 CISG80-65-125 CIW80-65-125 CIL80-65-125	30	8.33	22.5		2.87			64	3
	50	13.89	20	2980	3.63	5.5	Y132S1-2(V1)	75	3	133	80	65	53.5
	60	16.67	18		3.97			74	3.5
CISL80-65-160 CISG80-65-160 CIW80-65-160 CIL80-65-160	30	8.33	36		4.82			61	2.5
	50	13.89	32	2980	5.97	7.5	Y132S2-2(V1)	73	2.5	163	80	65	44
	60	16.67	29		6.58			72	3
CISL80-50-200 CISG80-50-200 CIW80-50-200 CIL80-50-200	30	8.33	53		7.87			55	2.5
	50	13.89	50	2980	9.87	15	Y160M2-2(V1)	69	2.5	197	80	50	48
	60	16.67	47		10.8			71	3
CISL80-50-250 CISG80-50-250 CIW80-50-250 CIL80-50-250	30	8.33	84		13.2			52	2.5
	50	13.89	80	2980	17.29	22	Y180M-2(V1)	63	2.5	243	80	50	86
	60	16.67	75		19.14			64	3
CISL80-50-315 CISG80-50-315 CIW80-50-315 CIL80-50-315	30	8.33	128		25.5			41	2.5
	50	13.89	125	2980	31.5	37	Y200L2-2(V1)	54	2.5	307	80	50	109
	60	16.67	123		35.3			57	3
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
CISL100-80-125 CISG100-80-125 CIW100-80-125 CIL100-80-125	60	16.67	24		5.85			67	4
	100	27.78	20	2980	6.98	11	Y160M1-2(V1)	78	4.5	135	100	80	58
	120	33.33	16.5		7.29			74	5
CISL100-80-160 CISG100-80-160 CIW100-80-160 CIL100-80-160	60	16.67	36		8.4			70	3.5
	100	27.78	32	2980	11.2	15	Y160M2-2(V1)	78	4	165	100	80	79
	120	33.33	28		12.2			75	5
CISL100-65-200 CISG100-65-200 CIW100-65-200 CIL100-65-200	60	16.67	54		13.6			65	3
	100	27.78	50	2980	17.9	22	Y180M-2(V1)	76	3.6	198	100	65	56
	120	33.33	47		19.9			77	4.8
CISL100-65-250 CISG100-65-250 CIW100-65-250 CIL100-65-250	60	16.67	87		23.4			61	3.5
	100	27.78	80	2980	30.3	37	Y200L2-2(V1)	72	3.8	248	100	65	95
	120	33.33	74.5		33.4			73	4.8
CISL100-65-315 CISG100-65-315 CIW100-65-315 CIL100-65-315	60	16.67	133		39.5			55	3
	100	27.78	125	2980	51.6	75	Y280S-2(V1)	66	3.6	307	100	65	130
	120	33.33	118		57.6			67	4.2
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
CISL125-100-200 CISG125-100-200 CIW125-100-200 CIL125-100-200	120	33.33	57.5		28			67	4.5
	200	55.56	50	2980	33.6	45	Y225M-2(V1)	81	4.5	210	125	100	87
	240	66.67	44.5		36.4			80	5
CISL125-100-250 CISG125-100-250 CIW125-100-250 CIL125-100-250	120	33.33	87		43.1			66	3.8
	200	55.56	80	2980	55.9	75	Y280S-2(V1)	78	4.2	248	125	100	125
	240	66.67	72		62.7			75	5
CISL125-100-315 CISG125-100-315 CIW125-100-315 CIL125-100-315	120	33.33	132.5		72.2			60	4
	200	55.56	125	2980	90.8	110	Y315S-2(V1)	75	4.5	308	125	100	125
	240	66.67	120		101.9			77	5
CISL125-100-400 CISG125-100-400 CIW125-100-400 CIL125-100-400	60	16.67	52		16			53	2.5
	100	27.78	50	1480	20.9	30	Y200L-4(V1)	65	2.5	387	125	100	137
	120	33.33	48.5		23.7			67	3
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
CISL150-125-250 CISG150-125-250 CIW150-125-250 CIL150-125-250	120	33.33	22.5		10.4			71	3
	200	55.56	20	1480	13.4	18.5	Y180m-4(V1)	81	3	257	150	125	136
	240	66.67	17.5		14.7			78	3.5
CISL150-125-315 CISG150-125-315 CIW150-125-315 CIL150-125-315	120	33.33	34		15.87			70	2.5
	200	55.56	32	1480	22.06	30	Y200L-4(V1)	79	2.5	322	150	125	158
	240	66.67	29		23.69			80	3
CISL150-125-400 CISG150-125-400 CIW150-125-400 CIL150-125-400	120	33.33	53		27.9			62	2
	200	55.56	50	1480	36.3	45	Y225M-4(V1)	75	2.8	333	150	125	187
	240	66.67	46		40.6			74	3.5
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
CISL200-150-400 CISG200-150-400 CIW200-150-400 CIL200-150-400
	400	111.1	20	1480	26.57	37	Y225S-4(V1)	82	4.6	269	200	150	N/A

CISL200-150-315 CISL200-150-315 CIW200-150-315 CIL200-150-315	240	66.67	37		34.5			70	3
	400	111.1	32	1480	42.5	55	Y250M-4(V1)	82	3.5	329	200	150	168
	460	127.8	28.5		44.6			80	4
CISL200-150-400 CISG200-150-400 CIW200-150-400 CIL200-150-400	240	66.67	55		48.6			74	3
	400	111.1	50	1480	67.2	90	Y280M-4(V1)	81	3.8	387	200	150	186
	460	127.8	45		74.2			76	4.5
——END——
