CB Type IY Oil pump

IY type single-stage single-suction oil transfer centrifugal pump is suitable for conveying non-corrosive oils and petroleum products without solid particles and with a viscosity less than 120 centimeters. The conveying medium temperature is -20℃~80℃ and the allowable inlet pressure is 0.6 MPa.

The pump is installed horizontally, with horizontal axial suction and three discharge directions: R, L, and T. From the suction end, the discharge is facing right, left, and upward respectively. The pump is a suspension structure. When inspecting, it is not necessary to disassemble the inlet and outlet pipes, and the rotor components can be removed for inspection. The shaft seal adopts soft packing seal. The bearing is a single-row radial ball bearing, lubricated with lubricating oil.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.

If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

General Specifications of IY Series

Flow range:	6.3~ 200 m³/h
Head range:	8~125 m

IY Model Description

IY100-65JR-200
IY- Single-stage single-suction oil transfer centrifugal pump
100- Inlet diameter (mm)
65- Exhaust diameter (mm)
J- Indicates reduced speed use
R- From the suction end, the outlet direction is right
200- Impeller nominal diameter (mm)

Search by Pump Type

Click Kit Name to Check Part List

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
T	7.5	2.08	34.3	2980	1.59		YB100L-2	44	2.0	154	50	32	48
IY50-32R-160	12.5	3.47	32.0		22.00	3		54	2.0
L	15.0	4.17	29.6		2.16			56	2.5
T	3.75	1.04	8.5	1480	0.25		YB801-4	35	2.0	154	50	32	48
IY50-32JR-160	6.3	1.75	8.0		0.29	0.55		48	2.0
L	7.5	2.08	7.5		0.31			49	2.5
T	7.5	2.08	52.5	2980	2.82		YB132S₁-2	38	2.0	193	50	32	54
IY50-32R-200	12.5	3.47	50		3.55	5.5		48	2.0
L	15.0	4.17	48		3.84			51	2.5
T	3.75	1.04	13.1	1480	0.41		YB802-4	33	2.0	193	50	32	54
IY50-32JR-200	6.3	1.75	12.5		0.51	0.75		42	2.0
L	7.5	2.08	12		0.56			44	2.5
T	7.5	2.08	82	2980	5.88		YB160M₁-2	28.5	2.0	243	50	32	96
IT50-32R-250	12.5	3.47	80		7.17	11		38	2.0
L	15.0	4.17	78.5		7.82			41	2.5
T	3.75	1.04	20.5	1480	0.91		YB90L-4	23	2.0	243	50	32	96
IY50-32JR-250	6.3	1.75	20.0		1.07	1.5		32	2.0
L	7.5	2.08	19.5		1.14			35	2.5
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
T	15.0	4.17	35	2980	2.65		YB132S₁-2	54	2.0	161	65	50	48
IY65-50R-160	25.0	6.94	32		3.35	5.5		65	2.0
L	30.0	8.33	30		3.71			66	2.5
T	7.5	2.08	8.8	1480	0.36		YB802-4	50	2.0	161	65	50	48
IY65-50JR-160	12.5	3.47	8.0		0.45	0.75		60	2.0
L	15.0	4.17	7.2		0.49			60	2.5
T	15.0	4.17	53	2980	4.42		YB132S₂-2	49	2.0	195	65	40	48
IY65-40R-200	25.0	6.94	50		5.67	7.5		60	2.0
L	30.0	8.33	47		6.29			61	2.5
T	7.5	2.08	13.2	1480	0.63		YB90S-4	43	2.0	195	65	40	48
IY65-40JR-200	12.5	3.47	12.5		0.77	1.1		55	2.0
L	15.0	4.17	11.8		0.85			57	2.5
T	15.0	4.17	82	2980	9.05		YB160M₂-2	37	2.0	247	65	40	103
IY65-40R-250	25.0	6.94	80		10.89	15		50	2.0
L	30.0	8.33	78		122.00			53	2.5
T	7.5	2.08	21	1480	1.23		YB100L₁-4	35	2.0	247	65	40	103
IY65-40JR-250	12.5	3.47	20		1.48	2.2		46	2.0
L	15.0	4.17	19.4		1.65			48	2.5
T	15.0	4.17	127	2980	18.50		YB200L₁-2	28	2.5	307	65	40	113
IY65-40R-315	25.0	6.94	125		21.30	30		40	2.5
L	30.0	8.33	123		22.80			44	3.0
T	7.5	2.08	32.3	1480	2.64		YB112M-4	25	2.5	307	65	40	113
IY65-40JR-315	12.5	3.47	32.0		2.94	4		37	2.5
L	15.0	4.17	31.7		3.16			41	3.0
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
T	30	8.33	36	2980	4.82		YB132S₂-2	61	2.5	163	80	65	51
IY80-65R-160	50	13.89	32		5.97	7.5		73	2.5
L	60	16.67	29		6.58			72	3.0
T	15	4.17	9	1480	0.67		YB90L-4	55	2.5	163	80	65	51
IY80-65JR-160	25	6.94	8		0.79	1.5		69	2.5
L	30	8.33	7.2		0.87			68	3.0
T	30	8.33	53	2980	7.87		YB160M₂-2	55	2.5	197	80	50	55
IY80-50R-200	50	13.89	50		9.87	15		69	2.5
L	60	16.67	47		10.82			71	3.0
T	15	4.17	13.2	1480	1.06		YB100L₁-4	51	2.5	197	80	50	55
IY80-50JR-200	25	6.94	12.5		1.31	2.2		65	2.5
L	30	8.33	11.8		1.44			67	3.0
T	30	8.33	84	2980	13.20		YB180M-2	52	2.5	243	80	50	101
IY80-50R-250	50	13.89	80		17.30	22		63	2.5
L	60	16.67	75		19.10			64	3.0
T	15	4.17	21	1480	1.75		YB100L₂-4	49	2.5	243	80	50	101
IY80-50JR-250	25	6.94	20		2.27	3		60	2.5
L	30	8.33	18.8		2.52			61	3.0
T	30	8.33	128	2980	25.50		YB200L₂-2	41	2.5	307	80	50	105
IY80-50R-315	50	13.89	125		31.50	37		54	2.5
L	60	16.67	123		35.50			57	3.0
T	15	4.17	32.5	1480	3.40		YB132S-4	39	2.5	307	80	50	105
IY80-50JR-315	25	6.94	32.0		4.19	5.5		52	2.5
L	30	8.33	31.5		4.60			56	3.0
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
T	60	16.67	36	2980	8.40		YB160M₂-2	70	3.5	165	100	80	86
IY100-80R-160	100	27.78	32		11.20	15		78	4.0
L	120	33.33	29		12.20			75	5.0
T	30	8.33	9.2	1480	1.12		YB100L₁-4	67	2.0	165	100	80	86
IY100-80JR-160	50	13.89	8.0		1.45	2.2		75	2.5
L	60	16.67	6.8		1.56			71	3.5
T	60	16.67	54	2980	13.60		YB180M-2	65	3.0	198	100	65	86
IY100-65R-200	100	27.78	50		17.90	22		76	3.6
L	120	33.33	47		19.90			77	4.8
T	30	8.33	13.5	1480	1.84		YB112M-4	60	2.0	198	100	65	86
IY100-65JR-200	50	13.89	12.5		2.33	4		73	2.0
L	60	16.67	11.8		2.61			74	2.5
T	60	16.67	87	2980	23.30		YB200L₂-2	61	3.5	248	100	65	107
IY100-65R-250	100	27.78	80		30.30	37		72	3.8
L	120	33.33	74.5		33.40			73	4.8
T	30	8.33	21.3	1480	3.16		YB132S-4	55	2.0	248	100	65	107
IY100-65JR-250	50	13.89	20		4.00	5.5		68	2.0
L	60	16.67	19		4.44			70	2.5
T	60	16.67	133	2980	39.50		YB280S-2	55	3.0	307	100	65	164
IY100-65R-315	100	27.78	125		51.60	75		66	3.6
L	120	33.33	118		57.60			67	4.2
T	30	8.33	34	1480	5.45		YB160M-4	51	2.0	307	100	65	164
IY100-65JR-315	50	13.89	32		6.92	11		63	2.0
L	60	16.67	30		7.66			64	2.5
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
T	120	33.33	132.5	2980	72.20		YB315S-2	60	4.0	308	125	100	163
IY125-100R-315	200	55.56	125		90.80	110		75	4.5
L	240	66.67	120		101.90			77	5.0
T	60	16.67	33.5	1480	9.40		YB160L-4	58	2.5	308	125	100	163
IY125-100JR-315	100	27.78	32.0		11.90	15		73	2.5
L	120	33.33	30.5		13.50			74	3.0
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
T	120	33.33	34	1480	15.87		YB200L-4	70	2.5	318	150	125	195
IY150-125R-315	200	55.56	32		226.00	30		79	2.5
L	240	66.67	29		23.69			80	3.0
——END——
