CB Type SLZ Clean Water Pump

SLZ type is a vertical single-stage double-suction centrifugal pump with vertical split, suitable for factories, cities, mines, power stations, farmland water conservancy projects and other fields. This type of pump is used to transport clean water without solid particles or other liquids with physical and chemical properties similar to water. The temperature of the medium being transported is 0~80 ℃, and the maximum allowable inlet pressure is 0.6 MPa.

The pump is installed vertically, with the suction port and discharge port both in the horizontal direction. The separation surface of the pump body and the pump cover is vertically separated on the axis center line. When inspecting, it is not necessary to disassemble the water inlet and outlet pipes and the motor. The pump cover can be opened and the rotor parts can be taken out. The upper bearing of the pump adopts a rolling bearing, which is lubricated with grease, and a cooling cavity is provided on the bearing body. The lower bearing of the pump is a guide bearing, which is lubricated and cooled by the pump’s own water. The shaft seal adopts two forms: soft packing seal and mechanical seal.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.

If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

Oops! It seems that the entered tour doesn't exist. Please enter correct shortcode.

General Specifications of s SLZ Series

Flow range:	200~6300 m³/h
Head range:	13.5~142 m

SLZ Model Description

10SLZ-9
10-intake diameter divided by 25 (i.e. inlet diameter is 250 mm)
SLZ-vertical single-stage double-suction axial split-center direct-connected centrifugal pump
9-divided by 10 to get the integer of the specific speed

Search by Pump Type

Click Kit Name to Check Part List

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
8SLZ-6	200	55.6	131	2970	93.9	160	Y315L1-2	76	4.0	302	200	125	380
	280	77.8	120		114.5			80	5.5
	316	87.8	110		121.4			78	8.8
8SLZ-9	218	60.6	77	2970	56.5	90	Y280M-2	80	3.5	238	200	150	360
	280	77.8	70		67.3			85	4.4
	340	94.4	59.5		78.3			80.5	6.2
8SLZ-12	235	66.1	51	2970	41.9	55	Y250M-2	78		197	200	150	330
	280	77.8	48		44.7			82	7.5
	380	105.6	36		46.6			80
8SLZ-18	250	69.4	31	2980	27.1	37	Y200L2-2	78		172	200	150	320
	280	77.8	30		27.4			83.5	8.0
	335	93.1	24.5		27			83
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
10SLZ-4	350	97.2	108	1480	139	220	Y355M1-4	74	2.0	538	250	200	1120
	485	134.7	100		167			79	2.6
	560	155.6	92		187			75	3.1
10SLZ-6	335	93.1	73	1480	86.5	132	Y315M-4	77	2.4	451	250	200	890
	485	134.7	65		104.8			82	3.4
	530	147.2	61		110			80	5.0
10SLZ-9	395	109.7	45	1480	58.4	90	Y280M-4	83	2.1	365	250	200	750
	485	134.7	42		63.4			87.5	2.6
	610	169.4	34		69.3			81.5	3.6
10SLZ-12	382	106.1	29	1480	37.7	55	Y250M-4	80		291	250	200	670
	485	134.7	26		40			86	4.1
	610	169.1	20		40.5			82
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
12SLZ-4	547	151.9	142	1480	284	400	YLS400-4	74.5	2.6	622	300	200	1980
	745	206.9	135.5		346			79.5	2.8
	820	227.8	126		363			77.5	3.6
12SLZ-6	472	131.1	102.5	1480	180.5	280	YLS355-4	73	2.9	532	300	200	1850
	790	219.4	90		239			80	4.8
	865	240.3	85		249			78	6.8
12SLZ-9	595	165.3	64	1480	125.8	200	Y315L2-4	82.5	3.1	435	300	250	1620
	790	219.4	60		148.5			87	3.4
	1030	286.1	49		169.8			81	5.2
12SLZ-12	650	180.6	41	1480	90.2	110	Y315S-4	80.5		347	300	250	1280
	790	219.4	38		96.8			84.5	6.1
	1040	288.9	29		99.6			82.5
12SLZ-18	625	173.6	24	1480	50.8	75	Y280S-4	80.5	3.8	296	300	250	1150
	790	219.4	22		54.4			87	4.4
	958	266.1	18.5		57.2			84.5	5.6
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
14SLZ-6	770	213.9	141.5	1480	393	630	YLS450-4	75.5	4.0	626	350	250	2060
	1260	350.0	125		517			83	6.4
	1400	388.9	117		551			81	9.3
14SLZ-9	972	270.0	80	1480	271	400	YLS400-4	78		492	350	250	1820
	1260	350.0	75		304			85	5.3
	1440	400.0	65		349			80
14SLZ-12	1030	286.1	56	1480	196.5	250	YLS355-4	80		403	350	300	1640
	1260	350.0	50		202			85	8.3
	1645	456.9	39.5		216			82
14SLZ-18	1060	294.4	31.5	1480	112	160	Y315L1-4	81	5.5	345	350	300	1420
	1260	350.0	30		121			85	5.9
	1625	451.4	23		121			84	8.0
14SLZ-30	972	270.0	20	1480	64	90	Y280M-4	83		290	350	350	1300
	1260	350.0	16		64.4			86	7.1
	1476	410.0	13.4		71			74
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
16SLZ-9	1120	311.1	97	1480	370	560	YLS400-4	80	6.0	533	400	300	2200
	1650	458.3	88		460			86	7.4
	1870	519.4	82		492			85	8.4
16SLZ-12	1320	366.7	64	1480	271	355	YLS400-4	85		437	400	300	1950
	1650	458.3	57		290			88.5	5.4
	1950	541.7	49		299			87
16SLZ-18	1340	372.2	38	1480	167	220	YLS355-4	83		377	400	350	1700
	1650	458.3	36		182			89	7.8
	1950	541.7	32		200			85
16SLZ-25	1320	366.7	23.5	1480	104	132	Y315M-4	81	7.0	330	400	400	1780
	1650	458.3	20		107			84	8.0
	1865	518.1	17		108			80	8.5
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
20SLZ-6	1580	438.9	108	980	567	800	YLS500-6	82	3.8	818	500	350	4710
	2160	600.0	95		666			84	6.3
	2310	641.7	90		699			81	8.4
20SLZ-10	1500	416.7	65.5	980	339	500	YLS450-6	79		690	500	400	4550
	2160	600.0	60		400			88	6.6
	2500	694.4	55.5		434			87
20SLZ-12	1615	448.6	43.5	980	235	280	YLS400-6	81.5		540	500	400	3400
	2160	600.0	38		257			87	6.5
	2585	718.1	30.5		260			83
20SLZ-18	1635	454.2	24	980	129	160	Y355M1-6	83	4.2	466	500	400	2650
	2160	600.0	22		149			87	5.2
	2285	634.7	18		137			82	6.6
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
24SLZ-9	2180	605.6	87	980	630	1000	YLS500-6	82	5.0	765	600	400	4850
	3240	900.0	79		793			88	6.7
	3770	1047.2	73		882			85	8.5
24SLZ-12	2250	625.0	59	980	436	560	YLS450-6	83		625	600	450	4540
	3240	900.0	50		496			89	7.5
	4050	1125.0	40		519			85
24SLZ-18	2700	750.0	33.5	980	291.7	355	YLS400-6	84.5		550	600	500	4220
	3240	900.0	32		317			89	7.0
	3600	1000.0	26		298			85.5
24SLZ-21	2016	560.0	33	985	218	250	YLS355-6	83	4.2	525	600	500	2070
	2992	831.1	25.3		232			89	5.0
	3456	960.0	21		227			87	6.3
24SLZ-25	2390	663.9	18.5	980	145	160	Y355M-6	83	5.8	447	600	600	3800
	2790	775.0	16		140			87	6.2
	3120	866.7	13.5		142			81	6.8
——END——
