CB Type SG Clean Water Pump

SG type single-stage, double-suction horizontal split-case high-efficiency centrifugal pump is a new generation of high-efficiency double-suction split-case pump designed and manufactured by our company with 60 years of pump manufacturing technology. This series of pumps are mature, reliable and efficient, and are suitable for factories, cities, chemical industry, steel, mines, power stations, farmland, water conservancy projects, sand suction ship projects and other fields. It is used to transport clean water without solid particles or other liquids with physical and chemical properties similar to water. The temperature of the medium to be transported is 0 ℃~80 ℃, and the maximum allowable inlet pressure is 0.6 MPa.

SG pump is mainly composed of pump body, pump cover, rotor parts (impeller, shaft, bearing body, etc.), sealing ring, coupling; and its accessories: water seal pipe parts, cooling water pipe parts, leaking water receiving parts, anchor bolts, coupling cover, motor, common base and other parts. The shell is open-type design, easy to disassemble and convenient for maintenance. When parts need to be replaced, there is no need to move the pump body and inlet and outlet pipes. The impeller adopts adjacent blade staggered design, so that after water enters both sides of the double-suction impeller, the hydraulic pulse is minimized, reducing vibration and noise. The patented large bearing body structure is adopted, and the installation position of the pump body bearing body is uniquely designed. The bearing of the large bearing body structure can be lubricated with grease or thin oil. All SG pump bearing bodies are connected with cooling water to ensure that the bearings can operate safely and stably under all working conditions.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.

If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

General Specifications of s SG Series

Flow range:	800~40000 m³/h
Head range:	6~160 m

SG Model Description

SGA400x300J
SG-double suction high efficiency split centrifugal pump
A-model code
400-inlet diameter (mm)
300-outlet diameter (mm)
J-speed reduction

Search by Pump Type

Click Kit Name to Check Part List

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA400×300	1200 1530 1870	77 70 58	1480	293 324 356	400	Y400-4	86 90 83	5.8 6.7 7.5	490	400	300
SGB400×300	1200 1530 1870	58 50 34	1480	221 232 233	280	Y355-4	86 90 83	3.8 4.9 6.7	435	400	300
SGB400×300I	1200 1530 1870	44 39 32	1480	173 183 192	220	Y355-4	83 89 85	4.9 5 5.2	390	400	300
SGC400×350	1200 1530 1870	37 34 26	1480	144 158 160	200	Y315L-4	84 90 83	46 5.3 7.8	375	400	350
SGC400×350I	1200 1530 1870	32 28 22	1480	122 130 135	160	Y315L-4	86 90 83	4.1 4.9 6.4	355	400	350
SGD400×350	1200 1530 1870	25 22 18	1480	100 102 107	132	Y315-4	82 90 86	5.6 6.2 7.3	315	400	350
SGE400×400	1200 1530 1720	19 17 14	1480	76 80 79	110	Y315-4	82 89 83	5.6 6.1 7.8	295	400	400
SGA400×300J	800 1020 1250	35 31 26	990	89 96 107	132	Y315L-6	86 90 83	3.1 3.5 3.9	490	400	300
SGB400×300J	800 1020 1250	26 22 17	990	67 68 70	90	Y315M-6	84 90 83	2.5 3 3.8	435	400	300
SGB400×300IJ	800 1020 1250	20 17 14	990	53 54 57	75	Y315S-6	82 88 84	2.6 3.1 3.5	390	400	300
SGC400×350J	800 1020 1250	17 15 12	990	44 46 51	75	Y315S-6	84 90 80	2.8 3 3.6	375	400	350
SGC400×350IJ	800 1020 1250	14 13 10	990	36 41 42	55	Y280M-6	85 89 82	2.3 2.7 3.4	355	400	350
SGD400×350J	800 1020 1250	11 10 8	990	29 31 32	37	Y250M-6	82 90 86	2.8 3.1 3.9	315	400	350
SGE400×400J	800 1020 1150	9 8 6	990	24 25 23	30	Y225M-6	82 89 83	2.8 3 3.9	295	400	400
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA500×400	2350 3000 3650	120 110 91	1480	894 988 1078	1250	Y500-4	86 91 84	9.3 10.5 11.7	615	500	400
SGA500×400I	2390 2990 3290	127 116 110	1480	973 1050 1147	1400	Y500-4	85 90 86	6 6.9 5.1	655	500	400
SGB500×400	2350 3000 3650	90 79 59	1480	640 702 699	900	Y450-4	90 92 84	5.8 7.6 10.5	545	500	400
SGB500×400I	2350 3000 3650	68 61 51	1480	518 560 590	710	Y450-4	84 89 86	7.6 7.8 8.2	486	500	400
SGC500×450	2350 3000 3650	58 52 40	1480	442 472 468	560	Y400-4	84 90 85	7.2 8.5 12.2	470	500	450
SGC500×450I	2350 3000 3650	50 45 35	1480	381 109 414	500	Y400-4	84 90 84	6.4 7.7 10	445	500	450
SGD500×450	2350 3000 3650	39 35 29	1480	301 318 332	400	Y400-4	83 90 87	8.7 9.6 11.3	395	500	450
SGE500×500	2350 3000 3360	30 26 22	1480	231 239 240	280	Y355-4	83 89 84	8.7 9.6 12.2	370	500	500
SGA500×400J	1570 2000 2440	54 49 41	990	269 293 325	400	Y400-6	86 91 84	4.2 4.7 5.2	615	500	400
SGA500×400IJ	1600 2000 2200	57 52 49	990	292 315 342	400	Y400-6	85 90 86	2.7 3.1 3.6	655	500	400
SGB500×400J	1570 2000 2440	40 35 24	990	214 207 199	250	Y355-6	80 92 80	2.9 3.8 5.3	545	500	400
SGB500×400IJ	1570 2000 2440	30 27 23	990	153 165 178	220	Y355L-6	84 89 86	3.9 4 4.2	486	500	400
SGC500×450J	1570 2000 2440	26 23 18	990	132 139 148	185	Y355M-6	84 90 81	3.6 4.3 6.1	470	500	450
SGC500×450IJ	1570 2000 2440	22 20 16	990	112 122 127	160	Y355M-6	84 89 84	3.4 3.9 4	445	500	450
SGD500×450J	1570 2000 2440	18 16 13	990	93 97 99	132	Y315L-6	83 90 87	4.4 4.8 5.7	395	500	450
SGE500×500J	1570 2000 2250	13 12 10	990	67 73 73	90	Y315M-6	83 89 84	4.4 4.8 6.1	370	500	500
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA600×450	3330 4200 5130	151 138 114	1480	1575 1736 1897	2240	Y630-4	87 91 84	11.6 13.1 14.7	690	600	450
SGB600×450	3330 4200 5130	112 99 68	1480	1129 1232 1174	1400	Y500-4	90 92 81	7.2 9.5 13.1	610	600	450
SGB600×450I	3330 4200 5130	85 76 64	1480	918 977 1040	1250	Y500-4	84 89 86	7.7 8.1 9.3	540	600	450
SGC600×500	3330 4200 5130	72 66 50	1480	769 839 832	1000	Y500-4	85 90 84	9 10.4 15	525	600	500
SGC600×500I	3330 4200 5130	64 56 44	1480	691 712 732	900	Y450-4	84 90 84	8 9.6 12.5	498	600	500
SGD600×500	3330 4200 5130	49 44 36	1480	529 560 578	710	Y450-4	84 90 87	11 12 15.3	440	600	500
SGE600×600	3330 4200 4720	37 33 27	1480	400 424 413	500	Y400-4	84 89 84	11 12 15.3	415	600	600
SGA600×450J	2220 2800 3430	68 62 51	990	473 520 567	710	Y500-6	87 91 84	5.2 5.9 6.6	690	600	450
SGB600×450J	2220 2800 3430	50 44 30	990	336 365 346	450	Y450-6	90 92 81	3.6 4.8 6.6	610	600	450
SGB600×450IJ	2220 2800 3430	38 34 29	990	274 291 315	400	Y400-6	84 89 86	3.9 4.1 4.7	540	600	450
SGC600×500J	2220 2800 3430	32 29 22	990	228 246 251	315	Y400-6	85 90 82	4.5 5.2 7.5	525	600	500
SGC600×500IJ	2220 2800 3430	29 25 20	990	209 214 223	250	Y355L-6	84 89 84	4.1 4.8 6.1	498	600	500
SGD600×500J	2220 2800 3430	22 20 16	990	158 170 172	200	Y355-6	84 90 87	5.5 6 7.7	440	600	500
SGE600×600J	2220 2800 3160	17 15 12	990	122 129 123	160	Y315M-6	84 89 84	5.5 6 7.7	415	600	600
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA700×500	4740 6000 7300	112 102 84	990	1644 1833 1966	2240	Y710-6	88 91 85	8.6 9.7 10.9	880	700	500
SGA700×500I	4000 4670 5340	110 107 98	990	1411 1530 1567	1800	Y630-6	85 89 91	8.2 9.3 10.7	874	700	500
SGB700×500	4740 6000 7300	83 73 50	990	1191 1297 1213	1600	Y630-6	90 92 82	5.4 7.1 9.7	785	700	500
SGB700×500I	4740 6000 7300	63 57 47	990	957 1036 1075	1400	Y560-6	85 90 87	9.6 9.7 10.2	700	700	500
SGC700×600	4740 6000 7300	53 49 37	990	796 880 887	1000	Y500-6	86 91 83	6.6 7.8 11.3	675	700	600
SGC700×600I	4740 6000 7300	47 41 32	990	714 745 749	900	Y500-6	85 90 85	5.9 7.1 9.2	640	700	600
SGD700×600	4740 6000 7300	36 32 27	990	554 581 610	710	Y500-6	84 90 88	8.1 8.9 10.5	570	700	600
SGE700×700	4740 6000 6710	28 24 20	990	425 436 430	500	Y450-6	85 90 85	8.1 8.9 11.3	530	700	700
SGA700×500J	3550 4500 5470	63 57 47	742	693 768 824	1000	Y560-8	88 91 85	48 5.4 6.2	880	700	500
SGA700×500IJ	3000 3500 4000	62 60 55	742	596 643 659	800	Y560-8	85 89 91	4.6 5.2 6	874	700	500
SGB700×500J	3550 4500 5470	47 41 31	742	505 546 544	630	Y500-8	90 92 85	3.7 4.7 6.3	785	700	500
SGB700×500IJ	3550 4500 5470	35 32 26	742	403 441 451	560	Y500-8	84 89 86	5.4 5.5 5.7	700	700	500
SGC700×600J	3550 4500 5470	30 27 21	742	337 364 377	450	Y450-8	86 91 83	4 4.7 6.8	675	700	600
SGC700×600IJ	3550 4500 5470	26 23 18	742	299 317 319	400	Y450-8	84 89 84	3.8 4.5 5.7	640	700	600
SGD700×600J	3550 4500 5470	20 18 15	742	230 245 254	315	Y450-8	84 90 88	4.9 5.3 6.3	570	700	600
SGE700×700J	3550 4500 5030	16 13 11	742	182 177 177	220	Y400-8	85 90 85	4.9 5.3 6.8	530	700	700
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA800×550	4000 4900 5400	155 150 143	750	2011 2302 2405	2500	N/A	84 87 88	4 4.5 5	1315	800	550
SGA800×600	6500 8200 10000	138 126 104	990	2778 3060 3334	4000	Y800-6	88 92 85	10.6 12 13.4	980	800	600
SGA800×600I	5100 6400 7700	141 130 117	1000	2449 2699 2888	3000	N/A	80 84 85	5.5 6 7	999	800	600
SGA800×600II	6670 8000 9190	123 110 98	990	2570 2694 2854	3550	N/A	87 89 86	8.9 10.3 11.6	985	800	600
SGB800×600	6500 8200 10000	102 90 62	990	1985 2162 2060	2500	Y710-6	91 93 82	6.7 8.8 12	870	800	600
SGB800×600I	6500 8200 10000	78 70 58	990	1625 1738 1817	2240	Y710-6	85 90 87	8.8 8.9 9.3	778	800	600
SGC800×700	6500 8200 10000	66 60 46	990	1359 1473 1510	1800	Y630-6	86 91 83	8.2 9.6 14	750	800	700
SGC800×700I	6500 8200 10000	58 51 40	990	1209 1252 1282	1600	Y630-6	85 91 85	7.3 8.8 11.4	710	800	700
SGD800×700	6500 8200 10000	45 40 33	990	938 982 1022	1250	Y560-6	85 91 88	10 11 13	630	800	700
SGE800×800	6500 8200 9200	34 30 25	990	709 745 737	900	Y500-6	85 90 85	10 11 14	590	800	800
SGA800×550J	3150 3850 4250	96 93 88	590	981 1121 1158	1400	Y630-10	84 87 88	3 3.3 3.5	N/A	800	550
SGA800×600J	4870 6150 7500	78 71 58	742	1176 1293 1395	1600	Y630-8	88 92 85	6 6.8 7.5	980	800	600
SGA800×600IJ	3780 4750 5710	78 72 64	742	1004 1109 1172	1400	Y630-8	80 84 85	3.5 3.8 4.3	999	800	600
SGA800×600IIJ	5000 6000 6885	69 62 55	742	1081 1139 1200	1400	Y630-8	87 89 86	5 5.8 6.5	985	800	600
SGB800×600J	4870 6150 7500	57 50 35	742	831 901 872	1120	Y630 8	91 93 82	4.1 4.7 5.4	870	800	600
SGB800×600IJ	4870 6150 7500	44 39 33	742	695 734 784	900	Y560-8	84 89 86	4.9 5 5.2	778	800	600
SGC800×700J	4870 6150 7500	37 34 26	742	571 626 640	800	Y560-8	86 91 83	4.5 4.9 5.9	750	800	700
SGC800×700IJ	4870 6150 7500	33 29 22	742	521 540 535	630	Y500-8	84 90 84	4.6 5.4 6.9	710	800	700
SGD800×700J	4870 6150 7500	25 22 18	742	390 405 418	500	Y500-8	85 91 88	5 5.2 5.7	630	800	700
SGE800×800J	4870 6150 6900	19 17 14	742	297 317 310	400	Y450-8	85 90 85	6 6.6 8.5	590	800	800
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA900×550	6400 7200 8000	156 150 141	750	3278 3504 3749	4000	N/A	83 84 82	7.1 8.1 9.4	1360	900	550
SGA900×650	6200 7000 7800	143 140 135.5	580	2911 3179 3429	N/A	N/A	83 84 84	4.5 5 5.5	1660	900	650
SGA900×700	7600 9600 11700	104 95 79	742	2448 2701 2963	3550	Y800-8	88 92 85	8.7 9.9 11.2	1140	900	700
SGB900×700	7600 9600 11700	77 68 47	742	1752 1913 1805	2240	Y710-8	91 93 83	5.5 7.3 9.9	1010	900	700
SGB900×700IJ	6040 7630 9300	37 34 28	590	716 785 816	1000	Y630-10	85 90 87	4.6 4.7 4.9	902	900	700
SGC900×800J	6040 7630 9300	32 28 22	590	620 647 672	800	Y560-10	85 90 83	4.3 5 7.3	870	900	800
SGC900×800IJ	6040 7630 9300	28 25 19	590	549 578 573	710	Y560-10	84 90 84	3.8 4.6 5.9	824	900	800
SGC900×800IIJ	4770 5960 7160	32 28 24	590	495 511 544	630	Y500-10	84 89 86	3.4 3.5 3.9	840	900	800
SGD900×800J	6040 7630 9300	21 19 16	590	411 439 466	560	Y500-10	84 90 87	5.2 5.7 6.8	730	900	800
SGE900×900J	6040 7630 8560	16 15 12	590	310 347 329	400	Y500-10	85 90 85	5.2 5.7 7.3	685	900	900
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA1000×600	6500 7500 8500	155 150 141	742	3230 3524 3798	4300	N/A	85 87 86	6.4 7.2 8	1330	1000	600
SGA1000×800	9500 12000 14640	121 110 91	742	3560 3910 4221	5000	Y900-8	88 92 86	10.1 11.5 12.8	1225	1000	800
SGB1000×800	9500 12000 14640	90 79 54	742	2560 2778 2596	3550	Y800-8	91 93 83	6.4 8.4 11.5	1090	1000	800
SGB1000×800I	9500 12000 14640	68 61 51	742	2047 2216 2312	2800	Y800-8	86 90 88	8.4 8.5 8.9	972	1000	800
SGC1000×900	9500 12000 14640	58 53 40	742	1726 1905 1900	2240	Y710-8	87 91 84	7.8 9.2 13.4	940	1000	900
SGC1000×900I	9500 12000 14640	51 45 35	742	1535 1617 1624	1800	Y710-8	86 91 86	7 8.5 10.9	886	1000	900
SGD1000×900	9500 12000 14640	39 35 29	742	1188 1258 1315	1600	Y630-8	85 91 88	9.6 10.5 12.4	790	1000	900
SGE1000×1000	9500 12000 13470	30 26 22	742	903 945 939	1120	Y630-8	86 90 86	9.6 10.5 13.4	740	1000	1000
SGA1000×800J	7550 9540 11640	77 70 58	590	1800 1978 2139	2500	Y800-10	88 92 86	6.4 6.5 8.1	1225	1000	800
SGB1000×800J	7550 9540 11640	57 50 34	590	1288 1398 1299	1600	Y710-10	91 93 83	4.3 5.6 7.7	1090	1000	800
SGB1000×800IJ	7550 9540 11640	43 39 32	590	1029 1127 1153	1400	Y630-10	86 90 88	5.3 5.4 5.6	972	1000	800
SGC1000×900J	7550 9540 11640	37 33 25	590	875 943 944	1120	Y630-10	87 91 84	5.2 6.2 9	940	1000	900
SGC1000×900IJ	7550 9540 11640	32 28 22	590	766 800 811	1000	Y630-10	86 91 86	4.4 5.4 6.9	886	1000	900
SGD1000×900J	7550 9540 11640	25 22 18	590	605 628 649	800	Y560-10	85 91 88	6.4 7 8.3	790	1000	900
SGE1000×1000J	7550 9540 10700	19 16 14	590	455 462 475	560	Y500-10	86 90 86	6.4 7 9	740	1000	1000
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA1100×700	11000 12500 13500	195 180 168	765	7001 7343 7578	8160	N/A	86 86 84	8.9 10 12	1480	1100	700
SGA1100×900	11100 14000 17070	99 90 74	590	3365 3692 4003	4500	Y900-10	89 93 86	8.9 10 11.2	1390	1100	900
SGB1100×900	11100 14000 17070	73 64 44	590	2426 2625 2466	3150	Y900-10	91 93 83	5.6 7.4 10	1235	1100	900
SGB1100×900I	11100 14000 17070	56 50 42	590	1970 2119 2220	2500	Y800-10	86 90 88	8.4 8.5 8.9	1105	1100	900
SGC1100×1000	11100 14000 17070	47 43 33	590	1643 1783 1827	2240	Y800-10	87 92 84	6.8 8 11.7	1065	1100	1000
SGC1100×1000I	11100 14000 17070	42 37 29	590	1477 1568 1569	1800	Y710-10	86 90 86	6.1 7.4 9.5	1010	1100	1000
SGD1100×1000	11100 14000 17070	32 29 24	590	1139 1216 1254	1400	Y630-10	85 91 89	8.4 9.2 10.9	895	1100	1000
SGE1100×1100	11100 14000 15700	24 22 18	590	844 933 895	1120	Y630-10	86 90 86	8.4 9.2 11.7	840	1100	1100
SGA1100×900J	9310 11750 14320	70 63 52	495	2018 2193 2387	2800	N/A	88 92 85	6.2 7 7.9	1390	1100	900
SGB1100×900J	9310 11750 14320	51 45 31	495	1438 1566 1457	1800	N/A	90 92 83	3.9 5.2 7	1235	1100	900
SGB1100×900IJ	9310 11750 14320	39 35 30	495	1150 1245 1330	1600	N/A	86 90 88	5.9 6 6.3	1105	1100	900
SGC1100×1000J	9310 11750 14320	33 30 23	495	973 1056 1068	1400	N/A	86 91 84	4.7 5.6 8.2	1065	1100	1000
SGC1100×1000IJ	9310 11750 14320	30 26 20	495	885 925 907	1120	N/A	86 90 86	4.3 5.2 6.7	1010	1100	1000
SGD1100×1000J	9310 11750 14320	23 20 17	495	686 704 745	900	Y630-12	85 91 89	5.9 6.5 7.7	895	1100	1000
SGE1100×1100J	9310 11750 13170	17 15 13	495	501 534 542	630	Y560-12	86 90 86	5.9 6.5 8.2	840	1100	1100
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGA1200×800	11000 12000 13000	188 180 169	775	6815 7118 7412	8320	N/A	86 86 84	9.3 10.1 11.5	1460	1200	800
SGA1200×900	13080 16500 20120	110 100 83	590	4405 4887 5291	6300	Y1000-10	89 92 86	9.9 11.2 12.7	1470	1200	900
SGB1200×900	13080 16500 20120	82 72 50	590	3177 3444 3303	4000	Y900-10	92 94 83	6.3 8.2 11.2	1305	1200	900
SGC1200×1000	13080 16500 20120	53 48 37	590	2171 2346 2415	2800	Y800-10	87 92 84	7.7 9 13	1125	1200	1000
SGC1200×1000I	13080 16500 20120	46 41 32	590	1906 2026 2040	2500	Y800-10	86 91 86	6.8 8.2 10.6	1065	1200	1000
SGD1200×1000	13080 16500 20120	36 32 26	590	1510 1564 1602	2000	Y710-10	85 92 89	9.3 10.3 12.1	945	1200	1000
SGE1200×1200	13080 16500 18500	27 24 20	590	1119 1186 1172	1400	Y630-10	86 91 86	9.3 10.3 13.1	885	1200	1200
SGA1200×900J	10980 13840 16880	77 70 58	495	2589 2870 3102	3550	Y1000-12	89 92 86	7 7.9 8.9	1470	1200	900
SGB1200×900J	10980 13840 16880	58 51 35	495	1886 2046 1940	2500	Y900-12	92 94 83	4.7 6.1 8.3	1305	1200	900
SGC1200×1000J	10980 13840 16880	37 34 26	495	1272 1394 1424	1800	Y800-12	87 92 84	5.7 6.7 9.6	1125	1200	1000
SGD1200×1000J	10980 13840 16880	25 23 18	495	880 943 930	1120	Y710-12	85 92 89	6.9 7.6 9	945	1200	1000
SGE1200×1200J	10980 13840 15520	19 17 14	495	661 705 688	900	Y630-12	86 91 86	6.9 7.6 9.7	885	1200	1200
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGB1400×1000	19030 24000 29280	105 92 64	590	5918 6401 6079	7100	Y1000-10	92 94 84	8 10.5 14.4	1480	1400	1000
SGB1400×1000I	19030 24000 29280	80 72 60	590	4824 5175 5440	6300	Y1000-10	86 91 88	8.2 8.3 8.8	1322	1400	1000
SGC1400×1200	19030 24000 29280	68 62 47	590	4053 4407 4412	5600	Y1000-10	87 92 85	9.8 11.5 16	1275	1400	1200
SGC1400×1200I	19030 24000 29280	60 52 41	590	3576 3737 3760	4500	Y900-10	87 91 87	8.8 10.5 13.7	1208	1400	1200
SGE1400×1200	16992 20520 23040	28 23 15.5	495	1457 1429 1106	1700	N/A	89 90 88	7 9 11	1020	1400	1200
SGE1400×1200J	14580 18396 19764	20.6 16.2 14	425	930 852 698	1120	N/A	88 90 88	5.4 7.5 8.5	1020	1400	1200
SGE1400×1400	19030 24000 26950	35 31 25	590	2086 2228 2110	2800	Y800-10	87 91 87	12 13 16	1000	1400	1400
SGA1400×1000J	15960 20130 24560	100 91 75	495	4887 5367 5769	7100	N/A	89 93 87	8.9 10.1 11.3	1665	1400	1000
SGB1400×1000J	15960 20130 24560	74 65 45	495	3498 3793 3585	4500	Y1000-12	92 94 84	5.9 7.8 10.7	1480	1400	1000
SGC1400×1200J	15960 20130 24560	48 44 33	495	2400 2623 2598	3150	Y900-12	87 92 85	7.3 8.5 11.8	1275	1400	1200
SGD1400×1200J	15960 20130 24560	32 29 24	495	1637 1729 1805	2240	Y800-12	85 92 89	8.9 9.6 11.8	1070	1400	1200
SGE1400×1400J	15960 20130 22600	25 22 18	495	1250 1326 1274	1600	Y800-12	87 91 87	8.9 9.6 11.8	1000	1400	1400
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGB1600×1200	26000 32800 40000	102 90 62	495	7855 8558 8045	10000	N/A	92 94 84	8.2 10.8 14.8	1740	1600	1200
SGC1600×1400	26000 32800 40000	66 60 46	495	5314 5829 5899	7100	N/A	88 92 85	10.1 11.8 17.2	1500	1600	1400
SGD1600×1400	26000 32800 40000	45 40 33	495	3707 3886 3997	5000	Y1000 12	86 92 90	12.3 13.5 16	1260	1600	1400
SGE1600×1600	26000 32800 36800	34 30 25	495	2801 2947 2882	3550	Y900-12	86 91 87	12 13 17	1180	1600	1600
SGA1600×1200J	22320 28160 34340	102 93 77	425	6893 7674 8282	10000	N/A	90 93 87	9.6 10.8 12.2	1960	1600	1200
SGB1600×1200J	22320 28160 34340	75 66 46	425	4958 5388 5124	6300	N/A	92 94 84	6.3 8.3 11.3	1740	1600	1200
SGC1600×1400J	22320 28160 34340	49 44 34	425	3387 3670 3743	4500	N/A	88 92 85	7.7 9 13	1500	1600	1400
SGD1600×1400J	22320 28160 34340	33 29 24	425	2334 2419 2495	3150	N/A	86 92 90	9.4 10.3 12.2	1260	1600	1400
SGE1600×1600J	22320 28160 31600	25 22 18	425	1768 1855 1782	2240	N/A	86 91 87	9.2 9.9 13	1180	1600	1600
——END——

ParameterType	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	Motor		Eff (η)	NPSH (r)	impolier Dia	Pump diameter
	Capacity (Q)	Head (H)	Speed (n)	Shaft power (Pa)	power	Type	Eff (η)	NPSH (r)	impolier Dia	Inlet Dia	Outlet Dia
	m³/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
SGE1800×1800	28800 36756 39204	21.4 18.8 14	372	1866 1859 1710	2300	N/A	90 90 82	6.8 7 7.5	1275	1800	1800
SGE1800×1800J	25920 29124 32796	17.1 15.1 11.3	333	1357 1346 1247	1600	N/A	89 89 81	5.4 5.6 6	1275	1800	1800
——END——
