CB Type CL, ClG,CBIQ Marine Pump

CL and CLG pumps are single-suction volute vertical vane pumps, and CBLQ pumps are serial and parallel volute vertical vane pumps, suitable for ship cooling systems, bilge ballast systems, circulating water systems, fire protection systems, auxiliary boiler water supply systems, daily water systems, etc. They are used to transport normal temperature seawater or fresh water on ships. The inlet pressure of CL and CBLQ pumps is allowed to be 0.6 MPa (6 kgf/cm²), and the inlet pressure of CLG pumps is allowed to be 3 MPa (30 kgf/cm²).

The pump and motor are connected together through the support. The pump feet installed on the side wall of CL and CLG are on the same vertical plane as the installation surface of the motor (or motor transition base). The pump suction port is vertically downward and the discharge port is horizontal. The CBLQ type is supported by a support frame and installed vertically. The pump shaft seal uses packing or mechanical seal. The difference between 8CLGIII-25 and 8CLGIII-25A is that the discharge direction differs by 90 degrees. The CBLQ type can be used in series or parallel through a reversing valve.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.

If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

General Specifications of CL, ClG,CBIQ Series

Flow range:	100~972 m³/h
Head range:	10~85 m

CL, ClG,CBIQ Model Description

8CLGIII-25
8-pump suction diameter divided by 25 (i.e. suction diameter is 200 mm)
CLG-vertical marine pump
III-third improvement
25-divisible divisor of specific speed by 10

Search by Pump Type

Click Kit Name to Check Part List

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
2CL-6	20	5.56	20	2950	2.79	4	Y112M-2-H	62	3	150	50	40	50


2CL-6A	18	5	24.5	2950	2.11	3	Y112M-2-H	62	3	138	50	40	50
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
2.5CL-6	30	8.33	45	2950	5.66	7.5	Y132S2-2-H	67	3	186	65	50	60
2.5CL-6A	27	7.5	37	2950	4.32	5.5	Y132S1-2-H	65	3	169	65	50	60
2.5CL-4	25	6.94	65	2950	10.56	15	Y160M1-2-H	44	5	230	65	50	65
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
3CL-10	50	13.89	30	2950	5.75	7.5	Y132S2-2-H	72	3.5	168	80	65	62
3CL-10A	45.5	12.64	25	2950	4.48	5.5	Y132S1-2-H	71	3.5	150	80	65	62
3CL-9	50	13.89	35	2950	6.8	7.5	Y132S2-2-H	71	5	182	80	65	64
3CL-6	50	13.89	65	2950	13.63	18.5	Y160L-2-H	65	4.5	235	80	50	127
3CL-6A	46.5	12.92	56	2950	11.06	15	Y160L-2-H	64	4.5	223	80	50	127
3CL-6B	44	12.22	50	2950	9.5	11	Y160L-2-H	63	4.5	210	80	50	127
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
4CL-14	100	27.8	30	2950	10.35	15	Y160M2-2-H	79	4.5	162	100	80	105
4CL-14A	90	25	24.5	2950	7.8	11	Y160M1-2-H	77	4.5	154	100	80	105
4CL-10	100	27.8	45	2950	16.8	22	Y180M-2-H	73	4	200	100	80	110
4CL-10A	90	25	36.5	2950	12.6	15	Y160M2-2-H	71	4	185	100	80	110
4CL-6	100	27.8	85	2950	34.6	45	Y225M-2-H	67	4	260	100	80	223
4CL-6A	92.5	25.7	73	2950	27.8	37	Y200L2-2-H	66	4	245	100	80	223
4CL-6B	87	24.2	64	2950	23.4	30	Y200L1-2-H	65	4	230	100	80	223
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
	100	27.8	57		20.7			75	4.9
5CLI-8	120	33.3	50	2980	22.1	30	JYZG200L1-2	74	5.4	218	125	100	387
	130	36.1	45		22.6			70.4	5.7
	100	27.8	53		19			76	4.9
5CLI-8A	120	33.3	46.5	2980	20.4	22	JYZG200L1-2	74.4	5.4	212	125	100	357
	130	36.1	41.1		20.9			69.7	5.7
6CL-18	162	45	30	2950	17	22	Y180M-2-H	78	4.5	185	125	100	120
6CL-18A	148	41.1	25	2950	13.3	18.5	Y160L-2-H	76	4.5	169	125	100	120
6CL-14	200	55.6	50	2950	34.9	45	Y225M-2-H	78	6	215	125	100	160
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
8CLGⅢ-25 8CLGⅢ-25A	200	55.6	31		23			73.4	6.1
	250	69.4	26	2980	23.3	30	JYZG200L1-2	76	6.7	184	200	175	470
	270	75	23.5		24			72	7.5
200CBLQ-13	(Series) 140 （in parallel) 280	(Series) 38.9 （in parallel) 77.8	80 40	2980	43.6	55	Submersible Motor	70	6	202	200	150	500
8CL-12	300	83.3	30	1450	30.6	37	Y225S-4-H	80	4	325	200	125	270
8CL-12A	262	72.8	23.5	1450	21.2	30	Y200L-4-H	79	4	305	200	125	270
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
10CLG-40 10CLG-40(Left)	600	166.7	13.4		26.2			83.5	3.9
	650	180.6	12.5	1480	25.5	30	JYZC225-4	86.7	4.2	296	250	250	722
	750	208.3	10.5		25.1			85.5	4.4
10CL-18	486	135	25	1450	40.9	45	Y225M-4-H	81	5	325	250	200	674
10CL-18A	443	123	20	1450	30.1	37	Y225S-4-H	80	5	308	250	200	674
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
300CLG-40 300CLG-40(Left)	684	190	15.38		36			79.5	4.2
	850	236.1	13	1480	36.3	45	JYZC225-4	83	5	238	300	300	950
	972	270	10.58		34.7			80.4	6.1
12CL-22	792	220	30	1450	79.9	90	Y280M-4-H	81	6	374	300	250	804
12CL-22A	720	200	25	1450	62.1	75	Y280S-4-H	79	6	342	300	250	804
——END——
