CB Type DYⅠ、DYⅡ、DYⅢ、DY、YD Chemical Pump

DYⅠ, DYⅡ, DYⅢ, DY, YD pumps are single suction multi-stage segmental centrifugal oil cooling pumps. Suitable for petrochemical plants, used to transport oils and petroleum products with a viscosity of less than 120 centistokes without solid particles. The medium temperature is t-20 ℃ ~ 150 ℃, and the allowable inlet pressure is 0.6 MPa.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.
Inlet and outlet: 100YD16 pump has horizontal suction and vertical discharge, and the others have vertical suction and vertical discharge.
Oil seal: Mechanical seal or packing seal can be used. The shaft seal has cooling.
Bearing type and lubrication; Sliding bearing forced circulation lubrication type includes DY850-125 pump; Sliding bearing oil ring splash oil lubrication type includes DYI85-67DYI155-67 and DYII 155-67 pumps; the others are rolling bearings, grease lubrication.
Support: The support of DYII 155-67 pump body is center support, and the other pumps are foot support.
If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

General Specifications of DYⅠ、DYⅡ、DYⅢ、DY、YD Series

Flow range:	6~850 m³/h
Head range:	48~648 m

DYⅠ、DYⅡ、DYⅢ、DY、YD Model Description

DY1155-67×5
DY single suction multi-stage segmental centrifugal oil pump
I-I material, cast iron; II is cast steel; III is cast stainless steel.
155-design flow rate (m³/h)
67-single-stage design head (m)
5-number of pump stages
YD80-30×5
YD single suction multi-stage centrifugal oil pump, cast iron

80-inlet diameter (mm)
30-single-stage design head (m)
5-number of pump stages
40YD-40×5
40-inlet diameter (mm)
YD single suction multi-stage centrifugal oil pump, cast iron
40-single-stage design head (m)
5-number of pump stages

Search by Pump Type

Click Kit Name to Check Part List

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
40YD40×3	6 10 12	1.67 2.78 3.33	123 120 115.5	2980	5.83 7.1 7.7	11	YB160M₁-2	34.5 46 49	2.6 3.3 3.9	168	40	40	125
40YD40×4	6 10 12	1.67 2.78 3.33	164 160 154	2980	7.77 9.47 10.27	15	YB160M₂-2	34.5 46 49	2.6 3.3 3.9	168	40	40	145
40YD40×5	6 10 12	1.67 2.78 3.33	205 200 192.5	2980	9.71 11.84 12.84	18.5	YB160L-2	34.5 46 49	2.6 3.3 3.9	168	40	40	165
40YD40×6	6 10 12	1.67 2.78 3.33	246 240 231	2980	11.65 14.21 15.41	18.5	YB160L-2	34.5 46 49	2.6 3.3 3.9	168	40	40	185
40YD40×7	6 10 12	1.67 2.78 3.33	287 280 269.5	2980	13.58 16.59 17.97	22	YB180M-2	34.5 46 49	2.6 3.3 3.9	168	40	40	205
40YD40×8	6 10 12	1.67 2.78 3.33	328 320 308	2980	15.52 18.96 20.56	22	YB180M-2	34.5 46 49	2.6 3.3 3.9	168	40	40	225
40YD40×9	6 10 12	1.67 2.78 3.33	369 360 346.5	2980	17.48 21.31 23.11	30	YB200L₁-2	34.5 46 49	2.6 3.3 3.9	168	40	40	245
40YD40×10	6 10 12	1.67 2.78 3.33	410 400 385	2980	19.4 23.7 25.7	30	YB200L₁-2	34.5 46 49	2.6 3.3 3.9	168	40	40	265
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
DY I 25-50×3	15 25 28	4.17 6.94 7.78	154.5 150 144	2980	14.3 18.9 20.3	30	YB200L₁-2	44 54 54	2.4 2.7 2.8	194	80	80	270
DY I 25-50×4	15 25 28	4.17 6.94 7.78	206 200 192	2980	19.1 25.2 27.1	30	YB200L₁-2	44 54 54	2.4 2.7 2.8	194	80	80	295
DY I 25-50×5	15 25 28	4.17 6.94 7.78	257.5 250 240	2980	23.9 31.5 33.9	37	YB200L₂-2	44 54 54	2.4 2.7 2.8	194	80	80	315
DY I 25-50×6	15 25 28	4.17 6.94 7.78	309 300 288	2980	28.6 37.8 40.7	45	YB225M-2	44 54 54	2.4 2.7 2.8	194	80	80	340
DY I 25-50×7	15 25 28	4.17 6.94 7.78	360.5 350 336	2980	33.4 44.1 47.5	55	YB250M-2	44 54 54	2.4 2.7 2.8	194	80	80	360
DY I 25-50×8	15 25 28	4.17 6.94 7.78	412 400 384	2980	38.2 50.4 54.2	75	YB280S-2	44 54 54	2.4 2.7 2.8	194	80	80	385
DY I 25-50×9	15 25 28	4.17 6.94 7.78	463.5 450 432	2980	43 56.7 61	75	YB280S-2	44 54 54	2.4 2.7 2.8	194	80	80	405
DY I 25-50×10	15 25 28	4.17 6.94 7.78	515 500 480	2980	47.7 63 67.8	75	YB280S-2	44 54 54	2.4 2.7 2.8	194	80	80	430
DY I 25-50×11	15 25 28	4.17 6.94 7.78	566 550 528	2980	52.5 69.3 74.6	90	YB280M-2	44 54 54	2.4 2.7 2.8	194	80	80	450
DY I 25-50×12	15 25 28	4.17 6.94 7.78	618 600 576	2980	57.3 75.6 81.4	110	YB315S-2	44 54 54	2.4 2.7 2.8	194	80	80	475
DY I 46-50×3	28 46 50	7.78 12.78 13.89	172.5 150 144	2980	24.8 29.8 31.1	37	YB200L₂-2	53 63 63	2.8 3.1 3.3	206	80	80	270
DY I 46-50×4	28 46 50	7.78 12.78 13.89	230 200 192	2980	33.1 39.8 41.5	45	YB225M-2	53 63 63	2.8 3.1 3.3	206	80	80	295
DY I 46-50×5	28 46 50	7.78 12.78 13.89	287.5 250 240	2980	41.4 49.8 51.9	55	YB250M-2	53 63 63	2.8 3.1 3.3	206	80	80	315
DY I 46-50×6	28 46 50	7.78 12.78 13.89	345 300 288	2980	49.6 59.7 62.2	75	YB280S-2	53 63 63	2.8 3.1 3.3	206	80	80	340
DY I 46-50×7	28 46 50	7.78 12.78 13.89	402.5 350 336	2980	57.9 69.7 72.6	90	YB280M-2	53 63 63	2.8 3.1 3.3	206	80	80	360
DY I 46-50×8	28 46 50	7.78 12.78 13.89	460 400 384	2980	66.2 79.6 83	90	YB280M-2	53 63 63	2.8 3.1 3.3	206	80	80	385
DY I 46-50×9	28 46 50	7.78 12.78 13.89	571.5 450 432	2980	74.4 86.6 92.9	110	YB315S-2	53 63 63	2.8 3.1 3.3	206	80	80	405
DY I 46-50×10	28 46 50	7.78 12.78 13.89	575 500 480	2980	82.7 99.5 103.7	132	YB315M₁-2	53 63 63	2.8 3.1 3.3	206	80	80	430
DY I 46-50×11	28 46 50	7.78 12.78 13.89	632.5 550 528	2980	91 109.5 114.1	132	YB315M₁-2	53 63 63	2.8 3.1 3.3	206	80	80	450
DY I 46-50×12	28 46 50	7.78 12.78 13.89	690 600 576	2980	99.3 119.4 124.5	132	YB315M₁-2	53 63 63	2.8 3.1 3.3	206	80	80	475
YD80-30×3	26 43 48	7.22 11.94 13.33	102 90 83	2980	12 15.1 15.7	18.5	YB160L-2	60 70 69	3 3.9 4.3	160	80	80	150
YD80-30×4	26 43 48	7.22 11.94 13.33	136 120 111	2980	16 20.1 21	22	YB180M-2	60 70 69	3 3.9 4.3	160	80	80	165
YD80-30×5	26 43 48	7.22 11.94 13.33	170 150 139	2980	20.1 25.1 26.3	30	YB200L₁-2	60 70 69	3 3.9 4.3	160	80	80	180
YD80-30×6	26 43 48	7.22 11.94 13.33	204 180 167	2980	24.1 30.1 31.6	37	YB200L₂-2	60 70 69	3 3.9 4.3	160	80	80	195
YD80-30×7	26 43 48	7.22 11.94 13.33	238 210 195	2980	28.1 35.1 36.9	45	YB225M-2	60 70 69	3 3.9 4.3	160	80	80	210
YD80-30×8	26 43 48	7.22 11.94 13.33	272 240 222	2980	32.1 40.1 42.1	55	YB250M-2	60 70 69	3 3.9 4.3	160	80	80	225
YD80-30×9	26 43 48	7.22 11.94 13.33	306 270 250	2980	36.1 45.2 47.4	55	YB250M-2	60 70 69	3 3.9 4.3	160	80	80	240
YD80-30×10	26 43 48	7.22 11.94 13.33	340 300 278	2980	40.1 50.2 52.7	55	YB250M-2	60 70 69	3 3.9 4.3	160	80	80	255
DY I,II80-30×3	25 40 50	6.94 11.11 13.89	94.5 79.5 61.5	2980	11.7 13.53 14.44	18.5	YB160L-2	55 64 58	3 4 4.5	160	80	80	165
DY I,II80-30×4	25 40 50	6.94 11.11 13.89	126 106 82	2980	15.6 18.04 19.25	22	YB180M-2	55 64 58	3 4 4.5	160	80	80	180
DY I,II80-30×5	25 40 50	6.94 11.11 13.89	157.5 132.5 102.5	2980	19.5 22.55 24.06	30	YB200L-2	55 64 58	3 4 4.5	160	80	80	195
DY I,II80-30×6	25 40 50	6.94 11.11 13.89	189 159 123	2980	23.4 27.06 28.88	37	YB200L₂-2	55 64 58	3 4 4.5	160	80	80	210
DY I,II80-30×7	25 40 50	6.94 11.11 13.89	220.5 185.5 143.5	2980	27.3 31.57 33.69	45	YB225M-2	55 64 58	3 4 4.5	160	80	80	225
DY I,II80-30×8	25 40 50	6.94 11.11 13.89	252 212 164	2980	31.2 36.08 38.5	55	YB250M-2	55 64 58	3 4 4.5	160	80	80	240
DY I,II80-30×9	25 40 50	6.94 11.11 13.89	283.5 238.5 184.5	2980	35.09 40.59 43.31	55	YB250M-2	55 64 58	3 4 4.5	160	80	80	255
DYI,II80-30×10	25 40 50	6.94 11.11 13.89	315 265 205	2980	38.99 45.1 48.13	55	YB250M-2	55 64 58	3 4 4.5	160	80	80	270
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
100YD16×3	36 54 72	10 15 20	60 51 33.5	2980	8.91 10.27 9.95	15	YB160M₂-2	66 73 66	3.7 3.9 4.3	132	100	100	170
100YD16×4	36 54 72	10 15 20	80 68 45	2980	11.88 13.7 13.37	15	YB160M₂-2	66 73 66	3.7 3.9 4.3	132	100	100	190
100YD16×5	36 54 72	10 15 20	100 85 56	2980	14.85 17.12 16.64	22	YB180M-2	66 73 66	3.7 3.9 4.3	132	100	100	210
100YD16×6	36 54 72	10 15 20	120 102 67	2980	17.83 20.55 19.9	22	YB180M-2	66 73 66	3.7 3.9 4.3	132	100	100	230
100YD16×7	36 54 72	10 15 20	140 119 78.5	2980	20.8 23.97 23.32	30	YB200L₁-2	66 73 66	3.7 3.9 4.3	132	100	100	250
100YD16×8	36 54 72	10 15 20	160 136 89.5	2980	23.77 27.4 26.59	30	YB200L₁-2	66 73 66	3.7 3.9 4.3	132	100	100	270
100YD16×9	36 54 72	10 15 20	180 153 101	2980	26.74 30.82 30	37	YB200L₂-2	66 73 66	3.7 3.9 4.3	132	100	100	290
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
DY I 85-67×3	55 85 100	15.28 23.61 27.78	222 201 183	2980	61.6 71.6 76.7	90	YB280M-2	54 65 65	3.3 4 4.4	233	150	150	846
DY I 85-67×4	55 85 100	15.28 23.61 27.78	296 268 244	2980	82.1 95.4 102.2	110	YB315S-2	54 65 65	3.3 4 4.4	233	150	150	964
DY I 85-67×5	55 85 100	15.28 23.61 27.78	370 335 305	2980	102.6 119.3 127.8	132	YB315M₁-2	54 65 65	3.3 4 4.4	233	150	150	1126
DY I85-67×6	55 85 100	15.28 23.61 27.78	444 402 365	2980	123.1 143.1 152.8	160	YB315M₂-2	54 65 65	3.3 4 4.4	233	150	150	1434
DY I 85-67×7	55 85 100	15.28 23.61 27.78	518 469 427	2980	143.7 167 178.9	200	YB400S-2	54 65 65	3.3 4 4.4	233	150	150	1556
DY I 85-67×8	55 85 100	15.28 23.61 27.78	592 536 488	2980	164.2 190.9 204.5	220	YB400S₂-2	54 65 65	3.3 4 4.4	233	150	150	1624
DY I 85-67×9	55 85 100	15.28 23.61 27.78	666 603 549	2980	184.7 214.7 230	250	YB400M1-2	54 65 65	3.3 4 4.4	233	150	150	1840
DY I 155-67×3	95 155 185	26.39 43.06 51.39	228 201 177	2980	93.6 114.7 122.2	132	YB315M₁-2	63 74 73	2.6 4.5 5.7	233	150	150	952
DY I 155-67×4	95 155 185	26.39 43.06 51.39	304 268 236	2980	124.8 152.9 162.9	185	YB315S₁-2	63 74 73	2.6 4.5 5.7	233	150	150	1024
DY I 155-67×5	95 155 185	26.39 43.06 51.39	380 335 295	2980	156.1 191.1 203.6	220	YB355S₃-2	63 74 73	2.6 4.5 5.7	233	150	150	1145
DY I 155-67×6	95 155 185	26.39 43.06 51.39	456 402 354	2980	187.3 229.3 244.3	280	YB355M-2	63 74 73	2.6 4.5 5.7	233	150	150	1435
DY I 155-67×7	95 155 185	26.39 43.06 51.39	532 469 413	2980	218.4 267.5 285	315	YB355L₁-2	63 74 73	2.6 4.5 5.7	233	150	150	1558
DY I 155-67×8	95 155 185	26.39 43.06 51.39	608 536 472	2980	249.7 305.7 325.9	355	YB355S₂-2	63 74 73	2.6 4.5 5.7	233	150	150	1700
DY I 155-67×9	95 155 185	26.39 43.06 51.39	684 603 531	2980	280.8 344 366.4	400	YB450S₃-2	63 74 73	2.6 4.5 5.7	233	150	150	1800
DYI155-67×3	95 155 815	26.39 43.06 51.39	219 192 168	2980	92.9 112.6 119.2	132	YB315M₁-2	61 72 71	2.6 4.5 5.7	233	150	150	620
DYI155-67×4	95 155 815	26.39 43.06 51.39	292 256 224	2980	123.8 150.1 158.9	185	YB355S₁-2	61 72 71	2.6 4.5 5.7	233	150	150	740
DYI155-67×5	95 155 815	26.39 43.06 51.39	365 320 280	2980	154.8 187.6 198.7	220	YB400S₂-2	61 72 71	2.6 4.5 5.7	233	150	150	860
DYI155-67×6	95 155 815	26.39 43.06 51.39	438 384 336	2980	185.8 225.1 238.4	280	YB400M₂-2	61 72 71	2.6 4.5 5.7	233	150	150	980
DYI155-67×7	95 155 815	26.39 43.06 51.39	551 448 392	2980	216.7 262.6 278.2	315	YB450S-2	61 72 71	2.6 4.5 5.7	233	150	150	1100
DYI155-67×8	95 155 815	26.39 43.06 51.39	584 512 448	2980	247.7 300.2 317.9	355	YB450S₂-2	61 72 71	2.6 4.5 5.7	233	150	150	1220
DYI155-67×9	95 155 815	26.39 43.06 51.39	657 576 504	2980	278.6 337.7 357.6	450	YB315M₁-2	61 72 71	2.6 4.5 5.7	233	150	150	1340
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/h	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
DY I 850-125×2	600 850 1270	166.7 236.1 352.8	260 250 160	2980	606.9 771.6 790.5	800	YB630S₁-2	70 75 70	18.5 24 24.7	363	300	300	3600
DY I 850-125×3	600 850 1270	166.7 236.1 352.8	390 375 240	2980	910.4 1157.4 1186	1250	YB710S₁-2	70 75 70	18.5 24 24.7	363	300	300	4300
DY I 850-125×4	600 850 1270	166.7 236.1 352.8	520 500 320	2980	1214 1543 1581	1800	YB710M₂-2	70 75 70	18.5 24 24.7	363	300	300	5000
DY I 850-125×5	600 850 1270	166.7 236.1 352.8	650 625 400	2980	1517 1929 1976	N/A	N/A	70 75 70	18.5 24 24.7	363	300	300	5700
——END——
