CB Type QZ Axial/Mixed Flow Pump

The QZ series submersible axial flow pump is a new generation product of the traditional water pump-motor unit. It is suitable for industrial and mining, docks, urban water supply and drainage and sewage engineering, as well as flood control projects. It is used to transport clean water below 40 ℃ or other liquids with physical and chemical properties similar to water. This type of pump is a large flow, low head pump.
The motor driving the water pump is a dry-type fully enclosed submersible three-phase asynchronous motor. This type of submersible electric pump can be immersed in water for a long time and has a series of advantages that traditional units cannot match.
The submersible motor of the submersible electric pump is placed above the pump. The submersible motor is a dry structure, adopts F-class insulation, reliable mechanical seals and auxiliary seals, and has leakage and internal winding temperature rise protection devices.
It adopts an excellent hydraulic model with high efficiency and good anti-cavitation performance. The impeller blades of the pump are semi-adjustable. Users can adjust the blade angle according to requirements to meet the requirements of changing working conditions. A water-lubricated bearing is set near the upper end of the impeller to reduce the extension length of the impeller shaft end and improve its stability.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.
If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

General Specifications of QZ Series

Flow range:	650~36000 m³/h
Head range:	1~13 m

QZ Model Description

20QZJ-2.1
20-pump outlet diameter 20 (500 mm)
QZ-submersible axial flow pump
J-pump speed change mark
2.1-design head 2.1 m

Search by Pump Type

Click Kit Name to Check Part List

Pump Performance Data Sheet

ParameterType	Head H	Capacity Q		Eff. η	Speed n	Motor		weight
	Head H	Capacity Q		Eff. η	Speed n	power	Type	weight
	m	m³/h	L/s	%	r/min	kW	Type	kg
	5.00	1854	515	76.0		33.3
20QZ-3.8(-2°)	3.22	2383	662	81.6	980	25.6	37	450
	1.90	2686	746	76.0		18.3
	5.10	2160	600	78.0		38.5
20QZ-3.8(0°)	3.50	2610	725	83.8	980	29.7	45	450
	1.90	2988	830	78.0		19.9
	5.22	2455	682	80.0		43.6
20QZ-3.8(+2°)	3.80	2848	791	84.8	980	34.8	45	450
	1.90	3312	920	77.0		22.3
	5.60	2556	710	78.0		50.0
20QZ-3.8(+4°)	4.02	3031	842	84.0	980	39.5	55	450
	1.90	3575	993	76.0		24.4
	5.10	3010	836	80.0		52.3
20QZ-3.8(+6°)	4.30	3240	900	81.9	980	46.4	55	450
	2.20	3780	1050	76.0		29.8
	8.40	2052	570	75.0		62.6
20QZ-6.1(-2°)	5.76	2603	723	83.6	980	48.9	75	450
	3.90	2808	780	76.0		39.3
	8.40	2196	610	76.0		66.1
20QZ-6.1(0°)	5.92	2786	774	84.3	980	53.3	75	450
	3.50	3078	855	75.0		39.2
	8.50	2430	675	77.0		73.1
20QZ-6.1(+2°)	6.07	2988	830	86.2	980	51.3	75	450
	3.50	3294	915	76.0		41.4
	8.85	2448	680	75.0		78.7
20QZ-6.1(+4°)	6.24	3139	872	85.7	980	62.3	90	450
	3.60	3506	974	76.0		45.3
	9.00	2538	705	75.0		83.0
20QZ-6.1(+6°)	6.34	3287	913	85.3	980	66.6	90	450
	3.60	3722	1034	75.0		48.7
	9.00	2722	756	76.0		87.8
20QZ-6.1(+8°)	6.44	3445	957	84.4	980	71.6	90	450
	3.70	3946	1096	75.0		53.0
	9.90	1980	550	75.0		71.2
20QZ-7.7(-2°)	7.10	2520	700	84.4	980	57.8	75	450
	4.30	2844	790	75.0		44.4
	9.60	2268	630	80.0		74.2
20QZ-7.7(0°)	7.34	2671	742	85.2	980	62.7	75	450
	4.00	3060	850	75.0		44.5
	10.40	2232	620	75.0		84.3
20QZ-7.7(+2°)	7.60	2808	780	86.3	980	67.4	90	450
	4.00	3258	905	75.0		47.4
	10.30	2340	650	77.0		85.3
20QZ-7.7(+3°)	7.70	2880	800	86.5	980	69.9	90	450
	4.20	3366	935	75.0		51.4
	10.30	2448	680	77.0		89.2
20QZ-7.7(+4°)	7.86	2956	821	86.2	980	73.4	90	450
	4.40	3463	962	75.0		55.4
	9.70	2772	770	82.0		89.3
20QZ-7.7(+6°)	8.17	3132	870	84.7	980	82.3	90	450
	5.00	3690	1025	75.0		67.0
	2.80	1415	398	77.0		14.0
20QZJ-2.1(-2°)	1.80	1771	492	81.6	730	10.7	15	450
	1.10	2002	556	76.0		8.1
	3.00	1512	420	75.0		16.5
20QZJ-2.1(0°)	1.95	1940	539	83.8	730	12.3	18.5	450
	1.00	2268	630	76.0		8.2
	3.10	1710	475	76.0		19.0
20QZJ-2.1(+2°)	2.10	2124	590	84.7	730	14.4	22	450
	1.00	2502	695	76.0		9.2
	3.10	1872	520	76.0		20.8
20QZJ-2.1(+4°)	2.20	2254	626	84.0	730	16.1	22	450
	1.10	2660	739	76.0		10.5
	2.90	2189	608	79.0		21.9
20QZJ-2.1(+6°)	2.37	2412	670	81.9	730	19.0	22	450
	1.27	2819	783	76.0		12.8
	4.50	1566	435	76.0		25.3
20QZJ-3.4(-2°)	3.17	1944	540	83.6	730	20.0	30	450
	2.20	2088	580	76.0		16.5
	4.60	1674	465	76.0		27.6
20QZJ-3.4(0°)	3.28	2077	577	84.3	730	22.0	30	450
	1.90	2990	36	76.0		15.6
	4.40	1909	530	79.0		29.0
20QZJ-3.4(+2°)	3.36	2232	620	86.1	730	23.8	30	450
	1.90	2462	684	76.0		16.8
	4.90	1829	508	75.0		32.6
20QZJ-3.4(+4°)	3.46	2340	650	85.7	730	25.8	37	450
	2.00	2606	724	77.0		18.5
	4.90	1922	534	75.0		34.2
20QZJ-3.4(+6°)	3.52	2434	676	85.4	730	27.3	37	450
	2.00	2772	770	76.0		19.9
	5.00	2009	558	77.0		35.6
20QZJ-3.4(+8°)	3.59	2563	712	85.4	730	29.7	37	450
	2.10	2905	807	76.0		21.9
	5.40	1494	415	76.0		28.9
20QZJ-4.3(-2°)	3.90	1872	520	84.3	730	23.6	30	450
	2.30	2124	590	75.0		17.8
	5.60	1598	444	75.0		32.5
20QZJ-4.3(0°)	4.06	1987	552	85.2	730	25.8	37	450
	2.20	2268	630	75.0		17.8
	5.70	1670	464	75.0		34.6
20QZJ-4.3(+2°)	4.20	2088	580	86.3	730	27.7	37	450
	2.30	2268	670	75.0		20.2
	5.70	1728	480	76.0		35.3
20QZJ-4.3(+3°)	4.28	2146	596	86.5	730	28.9	37	450
	2.30	2506	696	75.0		21.0
	5.70	1800	500	77.0		36.3
20QZJ-4.3(+4°)	4.33	2203	612	86.2	730	30.1	37	450
	2.40	2578	716	75.0		22.5
	5.40	2052	570	82.0		36.8
20QZJ-4.3(+6°)	4.52	2329	647	84.7	730	33.9	37	450
	2.70	2750	764	75.0		27.0
	5.20	4500	1250	80.0		79.7
28QZ-4.3(-2°)	3.80	5328	1480	83.0	730	66.5	80	650
	2.20	6120	1700	77.0		47.7
	5.70	4907	1360	80.0		95.0
28QZ-4.3(0°)	4.03	5940	1650	85.0	730	76.7	95	650
	2.20	6804	1890	78.0		52.3
	6.00	5400	1500	80.6		109.5
28QZ-4.3(+2°)	4.30	6408	1780	85.9	730	87.4	110	650
	2.20	7524	2090	78.0		57.8
	6.30	5688	1580	79.0		123.6
28QZ-4.3(+4°)	4.50	6840	1900	85.0	730	98.7	130	650
	2.40	7992	2220	78.0		67.0
	6.80	6048	1680	78.0		143.6
28QZ-4.3(+6°)	4.77	7380	2050	83.0	730	115.5	155	650
	2.50	8604	2390	77.0		76.1
	9.90	4896	1360	79.0		15.2
28QZ-7.0(-2°)	6.50	5904	1640	84.7	730	123.4	155	650
	4.00	6372	1770	76.0		91.4
	9.60	5040	1400	78.0		169.0
28QZ-7.0(0°)	6.80	6336	1760	85.4	730	137.4	180	650
	4.00	6876	1910	77.0		97.3
	10.00	5400	1500	77.0		191.0
28QZ-7.0(+2°)	7.03	6721	1867	87.1	730	147.8	200	650
	4.00	7416	2060	78.0		103.6
	10.00	5688	1580	78.0		198.6
28QZ-7.0(+4°)	7.22	7056	1960	86.7	730	160.0	210	650
	4.00	7884	2190	78.0		110.1
	10.00	6120	1670	79.0		207.3
28QZ-7.0(+6°)	7.45	7344	2040	86.4	730	172.5	245	650
	4.00	8316	2310	78.0		116.2
	10.50	6048	1680	78.0		221.8
28QZ-7.0(+8°)	7.70	7668	2130	85.4	730	188.3	245	650
	4.50	8676	2410	77.0		138.1
	11.40	4140	1150	77.0		167.0
28QZ-8.9(+4°)	7.85	5328	1480	84.0	730	135.3	180	650
	4.50	6012	1670	75.0		98.3
	11.40	4500	1250	78.0		179.1
28QZ-8.9(-2°)	8.20	5650	1570	85.5	730	149.4	180	650
	4.40	6480	1800	76.0		102.2
	11.80	4752	1320	78.0		195.8
28QZ-8.9(0°)	8.50	6012	1670	86.3	730	161.3	210	650
	10.30	6912	1920	76.0		106.5
	11.70	5200	1450	80.0		207.9
28QZ-8.9(+2°)	8.75	6300	1750	87.2	730	172.2	210	650
	4.40	7380	2050	76.0		116.4
	12.60	4914	1365	75.0		224.9
28QZ-8.9(+3°)	8.90	6444	1790	87.5	730	178.5	245	650
	4.50	7632	2120	76.0		123.1
	12.70	5076	1410	75.0		234.1
28QZ-8.9(+4°)	9.10	6624	1840	87.2	730	188.3	245	650
	4.50	7884	2190	75.0		128.9
	12.70	5436	1510	75.0		250.7
28QZ-8.9(+6°)	9.45	7020	1950	85.0	730	210.6	260	650
	5.20	8460	2350	75.0		159.8
	3.40	3373	937	77.0		40.6
28QZJ-2.8(-2°)	2.32	4248	1180	82.7	580	32.5	45	650
	1.40	4860	1350	77.5		24.0
	3.60	4194	1165	80.0		51.4
28QZJ-2.8(0°)	2.55	4651	1292	85.1	580	38.0	55	650
	1.54	5310	1475	80.0		27.9
	3.80	4266	1185	81.0		54.5
28QZJ-2.8(+2°)	2.80	5040	1400	85.8	580	44.8	55	650
	1.50	5904	1640	79.0		30.6
	4.10	4392	1220	79.0		62.1
28QZJ-2.8(+4°)	2.90	5220	1450	85.0	580	48.5	65	650
	1.65	6264	1740	79.0		37.5
	4.30	4716	1310	77.0		71.8
28QZJ-2.8(+6°)	3.00	5796	1610	83.0	580	57.1	75	650
	1.55	6840	1900	77.0		37.5
	6.00	3744	1040	78.0		78.5
28QZJ-4.4(-2°)	4.10	4680	1300	84.7	580	61.7	80	650
	2.30	5112	1420	75.0		42.7
	6.00	4176	1160	78.0		87.5
28QZJ-4.4(0°)	4.26	5004	1390	85.4	580	68.0	95	650
	2.40	5544	1540	77.0		47.1
	6.20	4356	1210	78.5		93.7
28QZJ-4.4(+2°)	4.42	5328	1480	87.1	580	73.7	95	650
	2.40	5940	1650	78.0		49.8
	6.50	4356	1210	77.0		100.2
28QZJ-4.4(+4°)	4.55	5616	1560	87.0	580	80.0	115	650
	2.50	6300	1750	78.0		55.0
	6.60	4536	1260	77.0		105.9
28QZJ-4.4(+6°)	4.66	5940	1650	86.4	580	87.3	115	650
	2.70	6606	1835	77.0		63.1
	6.40	5004	1390	79.0		110.4
28QZJ-4.4(+8°)	4.80	6138	1705	85.4	580	94.0	115	650
	2.70	6984	1940	77.0		66.7
	7.50	3384	940	75.0		92.2
28QZJ-5.6(-2°)	5.16	4644	1240	85.5	580	73.4	95	650
	3.00	5112	1420	77.0		54.3
	7.70	3636	1010	75.0		101.7
28QZJ-5.6(0°)	5.40	4752	1320	86.3	580	81.0	115	650
	3.00	5436	1510	76.0		57.0
	7.70	3888	1080	76.0		107.3
28QZJ-5.6(+2°)	5.54	5004	1390	87.2	580	86.6	115	650
	3.00	5796	1610	76.0		61.5
	7.70	3996	1110	76.0		110.3
28QZJ-5.6(+3°)	5.63	5126	1424	87.5	580	89.9	115	650
	3.00	6012	1670	76.0		64.7
	7.70	4212	1170	77.0		114.7
28QZJ-5.6(+4°)	5.75	5274	1465	87.2	580	94.7	115	650
	3.00	6228	1730	76.0		67.0
	7.80	4356	1210	76.0		121.8
28QZJ-5.6(+6°)	5.95	5580	1550	85.8	580	105.4	130	650
	3.50	6660	1850	76.0		83.6
	6.00	7920	2200	79.0		163.9
36QZ-4.8(-2°)	4.15	9486	2635	83.8	580	128.0	180	850
	2.50	10728	2980	79.0		92.5
	6.30	8856	2460	80.0		190.0
36QZ-4.8(0°)	4.45	10332	2870	85.8	580	146.0	200	850
	2.60	11736	3260	81.0		102.6
	6.25	9972	2770	83.0		204.5
36QZ-4.8(+2°)	4.75	11268	3130	86.0	580	168.4	210	850
	2.70	12852	3570	81.0		116.7
	7.00	10044	2790	80.0		239.4
36QZ-4.8(+4°)	5.00	11916	3310	85.9	580	188.9	250	850
	2.70	13788	3830	80.0		126.8
	7.00	11124	3090	80.0		265.0
36QZ-4.8(+6°)	5.30	12780	3550	84.1	580	219.4	280	850
	3.10	14544	4040	80.0		153.5
	10.00	8640	2350	79.0		291.7
36QZ-7.6(-2°)	7.15	10368	2880	85.6	580	235.9	310	850
	4.50	10584	2940	78.0		166.3
	9.50	9648	2680	82.0		304.4
36QZ-7.6(0°)	7.30	11088	3080	86.2	580	255.8	310	850
	4.50	12204	3390	79.0		189.4
	10.40	9720	2700	79.0		348.5
36QZ-7.6(+2°)	7.60	11952	3320	87.8	580	281.8	400	850
	4.50	13140	3650	80.0		201.3
	10.40	10440	2900	81.0		365.0
36QZ-7.6(+4°)	7.75	12528	3480	87.4	580	302.6	400	850
	4.50	13968	3880	80.0		214.0
	10.00	11412	3170	83.0		347.5
36QZ-7.6(+6°)	7.90	13104	3640	87.1	580	323.7	400	850
	4.70	14760	4100	79.0		239.2
	10.00	12240	3400	83.7		398.3
36QZ-7.6(+8°)	8.10	13788	3830	86.2	580	352.9	400	850
	5.00	15372	4270	80.0		261.7
	12.50	7740	2150	77.0		342.2
36QZ-9.7(-2°)	8.70	10080	2800	86.3	580	276.8	400	850
	5.30	11340	3150	78.0		209.9
	12.60	8568	2380	79.0		372.2
36QZ-9.7(0°)	9.10	10656	2960	87.0	580	303.6	400	850
	5.30	12060	3350	79.0		220.4
	12.50	9324	2590	81.0		391.9
36QZ-9.7(+2°)	9.45	11196	3110	87.9	580	327.8	400	850
	5.30	12888	3580	78.0		238.5
	13.40	8892	2470	76.0		427.0
36QZ-9.7(+3°)	9.65	11448	3180	88.2	580	341.1	480	850
	5.50	13356	3710	78.0		256.5
	13.40	9180	2550	76.0		440.8
36QZ-9.7(+4°)	9.80	11772	3270	87.8	580	357.9	480	850
	5.50	13788	3830	78.0		264.8
	13.40	9792	2720	77.0		464.1
36QZ-9.7(+6°)	10.30	12420	3450	86.6	580	402.3	480	850
	6.00	14796	4110	77.0		314.0
	4.20	6552	1820	79.0		94.9
36QZJ-3.4(-2°)	2.90	7992	2220	83.8	490	75.4	100	850
	1.80	9144	2540	79.0		56.8
	4.60	7128	1980	80.0		111.7
36QZJ-3.4(0°)	3.15	8748	2420	85.7	490	87.6	130	850
	1.86	10044	2790	81.0		62.9
	4.70	8064	2240	81.0		127.5
36QZJ-3.4(+2°)	3.40	9576	2660	86.6	490	102.4	130	850
	1.82	11160	3100	80.0		69.2
	5.20	8100	2250	78.0		147.1
36QZJ-3.4(+4°)	3.53	10188	2830	85.9	490	114.0	155	850
	2.00	11808	3280	80.0		80.4
	5.50	8712	2420	77.0		169.5
36QZJ-3.4(+6°)	3.75	10944	3040	84.1	490	132.9	180	850
	2.20	12492	3470	80.0		93.6
	7.20	7128	1980	79.0		177.0
36QZJ-5.4(-2°)	5.13	8784	2440	85.6	490	143.4	210	850
	3.00	9612	2670	77.0		102.0
	7.40	7560	2100	79.0		192.9
36QZJ-5.4(0°)	5.30	9432	2620	86.2	490	158.0	210	850
	3.00	10404	2890	78.0		109.0
	7.40	8280	2300	80.0		208.6
36QZJ-5.4(+2°)	5.40	10080	2800	87.8	490	168.9	210	850
	3.00	11124	3090	79.0		115.1
	7.90	8280	2300	78.0		228.4
36QZJ-5.4(+4°)	5.55	10620	2950	87.4	490	183.7	280	850
	3.00	11880	3300	79.0		122.9
	8.00	8532	2370	78.0		238.3
36QZJ-5.4(+6°)	5.65	11088	3080	87.1	490	195.9	280	850
	3.30	12456	3460	79.0		141.7
	8.10	8964	2490	78.0		253.6
36QZJ-5.4(+8°)	5.80	11664	3240	86.2	490	213.8	280	850
	3.30	13212	3670	78.0		152.3
	8.60	6804	1890	79.0		201.7
36QZJ-6.9(-2°)	6.20	8496	2360	86.3	490	166.3	210	850
	3.90	9504	2640	79.0		127.8
	9.00	7236	2010	79.0		224.5
36QZJ-6.9(0°)	6.50	9036	2510	87.0	490	183.9	280	850
	4.00	10116	2810	80.0		137.8
	9.20	7560	2100	78.0		242.9
36QZJ-6.9(+2°)	6.70	8468	2630	87.9	490	196.6	280	850
	4.00	10836	3010	70.0		147.6
	9.30	7704	2140	78.0		250.2
36QZJ-6.9(+3°)	6.85	9684	2090	88.2	490	204.9	280	850
	4.00	11268	3130	79.0		155.4
	9.40	7956	2210	78.0		261.2
36QZJ-6.9(+4°)	7.05	9936	2760	87.8	490	217.3	280	850
	4.00	11664	3240	78.0		162.9
	9.20	8676	2410	80.0		271.8
36QZJ-6.9(+6°)	7.34	10476	2910	86.8	490	241.9	280	850
	4.30	12492	3470	76.0		192.5
	5.80	10668	2963	79.0		213.4
48QZ-4.3(-2°)	4.00	13013	3615	83.8	490	169.3	220	1000
	2.45	14886	4135	79.0		125.8
	6.30	11606	3224	80.0		249.1
48QZ-4.3(0°)	4.30	14244	3957	85.7	490	194.8	280	1000
	2.52	16354	4543	81.0		236.6
	6.50	13130	3647	81.0		287.1
48QZ-4.3(+2°)	4.70	15592	4331	86.6	490	230.6	315	1000
	2.50	18172	5048	80.0		154.8
	7.15	13189	3664	78.0		329.5
48QZ-4.3(+4°)	4.85	16589	4608	85.9	490	255.2	355	1000
	2.74	19227	5341	80.0		179.5
	9.90	12095	3360	79.0		413.1
48QZ-7.3(-2°)	7.10	14303	3973	85.6	490	323.3	450	1000
	4.10	15651	4348	77.0		227.1
	10.20	12310	3419	79.0		433.1
48QZ-7.3(0°)	7.30	15358	4266	86.2	490	354.4	450	1000
	4.10	16941	4706	78.0		242.7
	10.20	13482	3745	78.0		480.4
48QZ-7.3(+2°)	7.40	16413	4550	87.8	490	376.9	500	1000
	4.10	18113	5031	79.0		256.1
	10.90	12310	3745	78.0		513.4
48QZ-7.3(+4°)	7.60	15358	4803	87.1	490	411.1	560	1000
	4.10	16941	5373	79.0		273.6
	11.90	11079	3078	79.0		454.8
48QZ-8.9(-2°)	8.50	13834	3843	86.3	490	320.4	500	1000
	5.30	15475	4299	79.0		282.9
	12.40	11782	3273	79.0		504.0
48QZ-8.9(0°)	8.90	14713	4087	87.0	490	410.2	560	1000
	5.50	16472	4576	80.0		308.6
	12.70	12310	3419	78.0		546.1
48QZ-8.9(+2°)	9.20	15417	4283	87.9	490	439.8	560	1000
	5.50	17644	4901	79.2		333.9
	13.00	12955	3599	78.0		588.4
48QZ-8.9(+4°)	9.70	16179	4494	87.8	490	487.1	630	1000
	5.50	18992	5276	78.0		365.0
	3.30	8056	2238	79.0		91.7
48QZJ-2.4(-2°)	2.25	9826	2729	83.8	370	71.9	111	1000
	1.40	11243	3123	79.0		54.3
	3.60	8764	2434	80.0		107.4
48QZJ-2.4(0°)	2.40	10756	2988	85.7	370	82.1	114	1000
	1.40	12349	3430	81.0		58.2
	3.70	9915	2754	81.0		123.4
48QZJ-2.4(+2°)	2.60	11744	3262	86.6	370	96.1	132	1000
	1.40	13721	3811	80.0		65.4
	4.10	9959	2766	78.0		142.6
48QZJ-2.4(+4°)	2.70	12526	3479	85.9	370	107.3	160	1000
	1.50	14518	4033	80.0		74.2
	5.60	8764	2434	79.0		169.3
48QZJ-4.1(-2°)	4.00	10800	3000	85.6	370	137.5	185	1000
	2.30	11818	3283	77.0		96.2
	5.80	9295	2582	79.0		186.0
48QZJ-4.1(0°)	4.10	11597	3221	86.2	370	150.3	220	1000
	2.30	12792	3603	78.0		104.2
	5.80	10180	2828	80.0		201.1
48QZJ-4.1(+2°)	4.20	12393	3443	87.8	370	161.6	220	1000
	2.30	13677	3796	79.0		108.4
	6.20	10180	2828	78.0		220.5
48QZJ-4.1(+4°)	4.30	13057	3672	87.4	370	175.1	25	1000
	2.30	14607	3908	79.0		111.6
	6.70	8365	2324	79.0		193.4
48QZJ-5.1(-2°)	4.85	10446	2902	86.3	370	160.0	220	1000
	3.05	11685	3246	79.0		122.9
	7.10	8897	2471	79.0		217.9
48QZJ-5.1(0°)	5.10	11110	3086	87.0	370	177.5	220	1000
	3.10	12438	3455	80.0		131.3
	7.20	9295	2582	78.0		233.8
48QZJ-5.1(+2°)	5.20	11641	3184	87.9	370	184.8	250	1000
	3.10	13323	3701	79.2		142.1
	7.40	9782	2717	78.0		252.9
48QZJ-5.1(+4°)	5.50	12216	3393	87.8	370	208.5	280	1000
	3.10	14341	3984	78.0		155.3
	4.70	13920	3867	79.0		225.7
56QZ-3.5(-2°)	3.25	16980	4717	83.8	370	179.5	250	1200
	2.00	19428	5397	79.0		134.0
	5.20	15144	4207	80.0		268.3
56QZ-3.5(0°)	3.50	18586	5163	85.7	370	206.9	280	1200
	2.10	21340	5928	81.0		150.8
	5.30	17133	4759	81.0		305.5
56QZ-3.5(+2°)	3.80	20345	5651	86.6	370	243.3	315	1200
	2.00	23711	6586	80.0		161.5
	5.90	17209	4780	78.0		354.7
56QZ-3.5(+4°)	4.00	21646	6013	85.9	370	274.7	400	1200
	2.20	25088	6969	80.0		188.0
	8.10	15144	4207	79.0		423.2
56QZ-6.0(-2°)	5.80	18663	5184	85.6	370	344.6	450	1200
	3.40	20422	5673	78.0		242.6
	8.40	16062	4462	79.6		461.9
56QZ-6.0(0°)	6.00	20039	5566	86.2	370	380.1	500	1200
	3.40	22105	6140	79.0		259.2
	8.40	17592	4887	80.0		503.4
56QZ-6.0(+2°)	6.10	21416	5949	87.8	370	405.5	560	1200
	3.40	23634	6565	79.0		277.2
	8.90	17592	4887	79.0		540.1
56QZ-6.0(+4°)	6.30	22564	6268	87.4	370	443.2	560	1200
	3.40	25241	7011	79.0		296.0
	9.70	14456	4016	80.0		477.7
56QZ-7.3(-2°)	7.00	18051	5014	86.3	370	399.0	500	1200
	4.40	20192	5609	80.0		302.6
	10.20	15374	4271	80.0		534.2
56QZ-7.3(0°)	7.30	19198	5333	87.0	370	439.0	560	1200
	4.50	21493	5970	81.0		325.4
	10.40	16062	4462	79.0		576.2
56QZ-7.3(+2°)	7.60	20116	5588	87.9	370	474.0	630	1200
	4.50	23022	6395	80.0		352.9
	10.60	16903	4695	79.0		618.0
56QZ-7.3(+4°)	8.00	21110	5864	87.8	370	524.2	630	1200
	4.50	24782	6884	79.0		384.7
	3.00	11099	3083	79.0		114.9
56QZJ-2.3(-2°)	2.05	13538	3761	83.8	295	90.3	132	1200
	1.30	15489	4303	79.0		69.5
	3.30	12074	3354	80.0		135.7
56QZJ-2.3(0°)	2.25	14819	4116	85.7	295	106.0	155	1200
	1.30	17014	4726	81.0		74.4
	3.35	13660	3794	81.0		153.9
56QZJ-2.3(+2°)	2.40	16221	4506	86.6	295	122.5	155	1200
	1.30	18905	5251	80.0		87.7
	3.70	13721	3811	78.0		177.3
56QZJ-2.3(+4°)	2.50	17258	4794	85.9	295	136.9	185	1200
	1.40	20002	5556	80.0		95.4
	5.20	12074	3354	79.0		216.6
56QZJ-3.8(-2°)	3.70	14880	4133	85.6	295	175.3	250	1200
	2.10	16282	4523	78.0		119.5
	5.30	12806	3557	79.6		232.3
56QZJ-3.8(0°)	3.80	15975	4438	86.2	295	191.9	250	1200
	2.10	17624	4896	79.0		127.7
	5.30	14026	3896	80.0		253.2
56QZJ-3.8(+2°)	3.90	17075	4743	87.8	295	206.7	280	1200
	2.10	18844	5234	79.0		136.5
	5.70	14026	3896	79.0		275.8
56QZJ-3.8(+4°)	4.00	17990	4997	87.4	295	224.4	280	1200
	2.10	20124	5590	79.0		145.8
	6.20	11525	3201	80.0		243.4
56QZJ-4.7(-2°)	4.45	14392	3998	86.3	295	202.2	280	1200
	2.80	16099	4472	80.0		153.6
	6.50	12257	3405	80.0		271.4
56QZJ-4.7(0°)	4.65	15306	4252	87.0	295	222.9	280	1200
	2.85	17136	4760	81.0		164.3
	6.60	12806	3557	79.0		291.5
56QZJ-4.7(+2°)	4.80	16038	4455	87.9	295	238.7	315	1200
	2.85	18356	5099	80.0		178.2
	6.75	13477	3745	79.0		313.9
56QZJ-4.7(+4°)	5.05	16831	4675	87.8	295	263.8	315	1200
	2.85	19758	5488	79.0		194.2
	4.00	19581	5439	79.0		297.2
64QZ-3.3(-2°)	3.00	23885	6635	84.0	295	232.5	315	1450
	1.85	27328	7591	79.0		174.4
	4.80	21303	5918	80.0		348.3
64QZ-3.3(0°)	3.30	26144	7262	85.7	295	274.3	355	1450
	1.92	30017	8338	81.0		193.9
	4.90	24100	6694	81.0		397.3
64QZ-3.3(+2°)	3.55	28619	7950	86.6	295	319.7	450	1450
	1.90	33353	9265	80.0		215.9
	5.45	24207	6724	79.0		455.1
64QZ-3.3(+4°)	3.70	30448	8458	85.9	295	357.4	500	1450
	2.10	35289	9803	80.0		252.4
	7.55	21303	5918	79.0		554.8
64QZ-5.6(-2°)	5.40	26252	7292	85.6	295	451.3	630	1450
	3.12	28726	7854	78.0		308.2
	7.80	22594	6276	79.6		603.3
64QZ-5.6(0°)	5.55	28188	7830	86.2	295	495.6	630	1450
	3.12	31093	8637	79.0		334.6
	7.80	24745	6874	80.0		657.5
64QZ-5.6(+2°)	5.65	30125	9368	87.8	295	540.9	710	1450
	3.12	33245	9235	79.0		357.8
	8.30	24745	6874	79.0		708.5
64QZ-5.6(+4°)	5.82	31739	8816	87.4	295	575.9	800	1450
	3.12	35505	9863	79.0		382.1
	9.05	20334	5648	80.0		626.7
64QZ-6.9(-2°)	6.50	25391	7053	86.3	295	521.1	710	1450
	4.10	28404	7890	80.0		396.7
	9.45	21625	6007	80.0		696.1
64QZ-6.9(0°)	6.85	27005	7501	87.0	295	579.4	800	1450
	4.20	30233	8398	81.0		427.2
	9.70	22594	6276	79.0		756.0
64QZ-6.9(+2°)	7.05	28296	7860	87.9	295	618.4	800	1450
	4.10	32384	8996	80.0		452.3
	9.90	23777	6605	79.0		812.0
64QZ-6.9(+4°)	7.40	29695	8249	87.8	295	682.0	900	1450
	4.10	34859	9683	79.0		493.0
	3.10	16395	4554	79.0		175.3
64QZJ-2.4(-2°)	2.14	19998	5555	84.0	247	138.8	220	1450
	1.33	22881	6356	79.0		105.0
	3.40	17836	4954	80.0		206.5
64QZJ-2.4(0°)	2.32	21890	6081	85.7	247	161.5	220	1450
	1.35	25133	6981	81.0		114.1
	3.47	20178	5605	81.0		235.6
64QZJ-2.4(+2°)	2.51	23962	6656	86.6	247	189.3	250	1450
	1.34	27926	7757	80.0		127.5
	3.84	20269	5630	79.0		268.5
64QZJ-2.4(+4°)	2.60	25493	7081	85.9	247	210.3	280	1450
	1.45	29547	8208	80.0		145.9
	5.32	17836	4954	79.0		327.3
61QZJ-3.9(-2°)	3.78	21986	6107	85.6	247	264.6	355	1450
	2.21	24052	6681	78.0		185.7
	5.46	18917	5255	79.6		353.6
61QZJ-3.9(0°)	3.90	23062	6406	86.2	247	284.3	400	1450
	2.21	26034	7232	79.0		198.5
	5.46	20719	5755	80.0		385.3
61QZJ-3.9(+2°)	3.95	25223	7006	87.8	247	309.2	400	1450
	2.21	27836	7732	79.0		212.2
	5.80	20719	5755	79.0		414.5
61QZJ-3.9(+4°)	4.10	26574	7382	87.4	247	339.7	450	1450
	2.21	29727	8258	79.0		226.6
	6.35	17025	4729	80.0		370.6
64QZJ-4.8(-2°)	4.56	21259	5905	86.3	247	306.1	400	1450
	2.85	23782	6606	80.0		230.9
	6.60	18107	5030	80.0		407.1
64QZJ-4.8(0°)	4.80	22611	6281	87.0	247	340.0	450	1450
	2.95	25313	7031	81.0		251.2
	6.80	18917	5255	79.0		443.7
64QZJ-4.8(+2°)	4.95	23692	6581	87.9	247	363.6	500	1450
	2.95	27115	7532	80.0		272.3
	6.95	19908	5530	79.0		477.3
64QZJ-4.8(+4°)	5.21	24863	6906	87.8	247	402.0	500	1450
	2.95	29187	8108	79.0		297.0
——END——
