CB Type SA，S Clean Water Pump

SA and S types are single-stage double-suction horizontal split centrifugal pumps suitable for factories, cities, mines, power stations, farmlands, water conservancy projects and other fields. They are used to transport clean water without solid particles or other liquids with physical and chemical properties similar to water. The temperature of the medium being transported is 0 ℃~80 ℃. The maximum allowable inlet pressure is 0.6 MPa.
The pump is installed horizontally, and the pump shell is split horizontally at the axis. The upper part is the pump cover, and the lower part is the pump body. The suction port and the discharge port are both on the pump body below the pump axis, and the center line is perpendicular to the axis. When inspecting, there is no need to dismantle the water inlet and outlet pipes, and the pump cover can be opened to take out the rotor parts. The shaft seal is a soft packing seal or a mechanical seal.EMAC will continue to update the product introduction pages of different standard versions of pumps. Please subscribe to our website to get the latest update information.
If you are in need of pumps model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at CB Pumps.

coming soon

General Specifications of s SA，S Series

Flow range:	72~10800 m³/h
Head range:	11~140 m

SA，S Model Description

10SA-6JA
10-suction diameter divided by 25 (i.e. suction diameter is 250 mm)
SA-single-stage double-suction horizontal split centrifugal pump
6-divided by 10 for specific speed
J-indicates the change in rated speed
A-indicates the first change in the outer diameter of the impeller, A, B, C… and so on 300S-19A
300-suction diameter 300 mm
S-single-stage double-suction horizontal split centrifugal pump
19-design point head
A-indicates the first change in the outer diameter of the impeller, A, B, C… and so on

Search by Pump Type

Click Kit Name to Check Part List

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
S150-97 (6SA-6)	126 180 216	35 50 60	104 97 87	2980	48.8 59.5 64.8	75	Y280S-2	73 80 79	3 3.8 5.3	270	150	100	150
S150-97A (6SA-6A)	119 170 204	33 47.2 56.6	91 84.5 76	2980	42 50.1 54.8	75	Y280S-2	70 78 77	3 3.7 4.7	255	150	100	150
S150-97B (6SA-6J)	72 90 108	20 25 30	24 22.5 20	1480	6.45 7.45 8.4	11	Y160M-4	73 74 70	2.6 2.7 2.9	270	150	100	110
S150-50 (6SA-8)	108 160 193	30 44.5 53.5	58 55 52	2980	24.6 30.1 33.3	37	Y200L2-2	69 81 82	2.9 3.8 4.4	205	150	100	110
S150-50A (6SA-8A)	108 144 174	30 40 48.3	45 43 39	2980	18.2 21.1 23.1	30	Y200L1-2	73 80 80	2.9 3.6 4.1	185	150	100	110
S150-50B (6SA-8B)	108 133 160	30 36.9 44.5	40 38 34	2980	15.86 17.7 19.4	22	Y180M-2	74 78 77	2.7 3.1 3.4	170	150	100	110
150S78	126 160 198	35 44.5 55	84 78 70	2980	40 45.3 51	55	Y250M-2	72 75 74	5.9	245	150	100	150
150S78A	112 144 180	31 40 50	67 62 55	2980	29.6 33.8 36.9	45	Y225M-2	68 72 70	5.9	220	150	100	150
150S78B	112 144 170	31 40 47	42 40 37	2980	20.5 22.4 25.2	37	Y200L2-2	68 70 68	5.9	190	150	100	150
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
S200-95 (8SA-7)	216 280 336	60 77.78 93.5	99 95 87	2980	78.6 90.8 101	132	Y315M-2	74 80 79	4 4.7 6.6	272	200	125	215
S200-95A (8SA-7A)	210 262 314	58.4 72.78 87.2	87 83 74	2980	68.1 76.9 83.3	110	Y315S-2	73 77 76	4 4.5 5.7	255	200	125	215
S200-95B (8SA-7B)	190 247 300	55 68.61 83.4	76 73 63	2980	57 64.6 71.4	75	Y280S-2	72 76 72	4 4.2 5.4	234	200	125	215
S200-63 (BSA-10)	194 280 351	54 77.78 97.5	71 63 52	2980	52 59.3 65.4	75	Y280S-2	72 81 76	2.8 4.1 5.3	235	200	150	235
S200-63A (8SA-10A)	180 259 324	50 71.94 90	58 52 41	2980	40.6 46.5 50.2	55	Y250M-2	70 79 72	2.7 3.8 4.9	217	200	150	235
S200-63B (8SA-10B)	173 239 288	48 66.4 80	48 44 36	2980	32.2 36.6 38.2	45	Y225M-2	70 78 74	2.6 3.5 4.2	200	200	150	235
200S42	216 280 342	60 78 95	48 42 35	2980	34.9 37.7 40.2	55	Y250M-2	81 85 81	5.4	204	200	150	200
200S42A	198 270 310	55 75 86	43 36 31	2980	30.5 33.1 34.4	37	Y200L2-2	76 80 76	5.4	193	200	150	200
200563	216 280 351	60 78 97.5	69 63 50	2980	55.1 59.3 67.8	75	Y280S-2	73.7 81 70.5	5.4	235	200	150	230
200S63A	180 270 324	50 75 90	54.5 46 37.5	2980	38.2 42.8 47.3	55	Y250M-2	70 79 70	5.4	215	200	150	230
200S63B	173 239 288	48 66 80	48 44 36	2980	32.2 36.6 38.2	45	Y225M-2	70 78 74	5.4	200	200	150	230
200S95	216 280 336	60 77.8 93.3	99 95 87	2980	78.6 90.8 101.1	110	Y315S-2	74 80 79	4 4.7 6.6	272	200	125	300
200S95A	210 262 314	58.3 72.8 87.2	87 83 74	2980	68.1 76.9 83.3	110	Y315S-2	73 77 76	4.5 5.7	255	200	125	300
200S95B	196 247 300	54.4 68.6 83.3	76 73 63	2980	57 64.6 71.4	75	Y280S-2	72 76 72	4 4.2 5.4	245	200	125	300
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
10SA-6	432 540 720	120 150 200	96 94 89	1480	152.6 177.2 215	250	Y355M2-4	74 78 81	5.1 6.3 9.2	530	250	200	600
10SA-6A	408 510 680	120 150 200	85.3 84 76	1480	129.3 154.5 186.3	220	Y355M1-4	77.6 80 80	5.1 6.3 9.2	500	250	200	600
10SA-6B	383 479 640	120 150 200	76.4 74 67	1480	121.5 137.8 164.3	185	Y315L-4	74 79 80	5.1 6.3 9.2	470	250	200	600
10SA-6J (10SA-6C)	400 500 600	111.1 138.8 166.6	42 39 35	980	58.7 65.6 72.5	95	Y315M-6	78 81 79	3.6 4.7 6.6	530	250	200	600
10SA-6JA (10SA-6D)	300 400 500	111.1 138.8 166.6	36.8 36 33	980	39.4 49.7 56.2	75	Y315S-6	76.4 79 80	3.3 3.6 4.7	500	250	200	600
10SA-6JB (10SA-6E)	300 400 500	111.1 138.8 166.6	33 32 28	980	34.8 44.1 48.3	55	Y280M-6	77.5 79 79	3.3 3.6 4.7	470	250	200	600
10SA-6F	400 500 600	111.1 138.8 166.6	66.4 65.6 62.5	1480	95.2 113.1 131	160	Y315L1-4	76 79 78	4.6 5.7 7.5	436	250	200	600
250S14	300 485 580	83 134.7 161	17.5 14 12	1480	19.7 22.6 23.3	30	Y200L-4	72.5 85.6 82.7	2 3.39 4.18	245	250	200	520
250S14A	320 430 504	88.8 119.4 140	13.7 11 8.6	1480	15.3 15.7 15.73	22	Y180L-4	78 82 75	3.2	226	250	200	520
250S24	360 485 576	100 134.7 160	27 24 19	1480	33.1 36.9 36.3	45	Y225M-4	80 86 82	3.5	285	250	200	580
250S24A	342 414 482	95 115 134	22.2 20.3 17.4	1480	25.8 27.6 28.6	37	Y225S-4	80 83 80	3.5	265	250	200	580
250S39	360 485 612	100 134.7 170	42.5 39 32.5	1480	54.8 62.1 68.6	75	Y280S-4	76 83 79	3.2	367	250	200	620
250S39A	324 468 576	90 130 160	35.5 30.5 25	1480	42.3 49.2 50.9	55	Y250M-4	74 79 77	3.2	338	250	200	620
250S65	360 485 582	80.8 134.7 162	71 65 60	1480	92.9 108.7 126.9	132	Y315M-4	75 79 75	3	450	250	200	831
250S65A	338 462 535	93.8 128.3 148.6	60 53 49	1480	74.7 86.6 95.2	110	Y315S-4	74 77 75	3	410	250	200	831
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
300S12	612 790 900	170 219 250	13.6 11.25 9.4	1480	30.2 31.1 33.1	37	Y225S-4	78 83 80	5.8	251	300	300	720
300S12A	515 675 781	143.1 187.5 216.9	11.5 9.7 8.5	1480	22.1 22.9 23.8	30	Y200L-4	73 78 76	5.8	222	300	300	720
300S19	612 790 935	170 219 260	22 19 14	1480	45.9 46.9 47.6	55	Y250M-4	80 87 75	5.8	290	300	250	1200
300S19A	485 693 798	134.7 192.5 221.7	18.5 14.8 12.1	1480	34.4 34.9 35.1	45	Y225M-4	71 80 75	5.8	260	300	250	1200
300S32	612 790 900	170 219 250	38 32 28	1480	76.2 79 86	110	Y315S-4	83 87 80	5.8	348	300	250	810
300S32A	537 702 790	149.2 195 219.4	29.5 24.7 22.8	1480	53.9 56.2 62.9	75	Y280S-4	80 84 78	5.8	318	300	250	810
300558	576 790 972	160 219 270	65 58 50	1480	136 148.5 165.5	185	Y315M1-4	75 84 80	5.8	435	300	250	943
300S58A	529 720 893	147 200 248	55 49 42	1480	107 118.6 131	160	Y315L1-4	74 81 78	5.8	410	300	250	943
300S58B	504 684 835	140 190 232	47.2 43 37	1480	88.8 100 108	132	Y315M-4	73 80 78	5.8	390	300	250	943
300S90	590 790 936	164 219 260	93 90 82	1480	202 242 279	315	Y355L-4	74 80 75	5.8	531	300	200	1056
300S90A	576 756 918	160 210 255	86 78 70	1480	190 217 247	280	Y355L1-4	71 74 71	5.8	500	300	200	1056
300S90B	540 720 900	150 200 250	72 67 57	1480	151 180 200	220	Y355M¹-4	70 73 70	5.8	470	300	200	1056
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
14SA-10	900 1080 1260	250 300 350	70 68 64	1480	206.5 230 250	315	Y355L2-4	83 87 88	4.1 4.6 5.4	466	350	300	1210
14SA-10A	900 1080 1260	250 300 350	60 58 54	1480	175 196 213	250	Y355M²-4	84 87 87	5.1 6.3 6.9	440	350	300	1210
14SA-108	900 1080 1260	250 300 350	51 48 44	1480	149 162.2 179.7	220	Y355M1-4	84 87 84	5.1 6.3 6.9	425	350	300	1210
14SA-10J (14SA-10C)	650 800 1000	180.56 222.22 277.78	30 28 24	980	66.6 72.6 78.7	90	Y315M-6	79.7 84 83	1.79 2.21 3.16	466	350	300	1210
14SA-10JA (14SA-10D)	600 720 900	166.6 200 250	27 25 22	980	54.9 57.9 64.2	75	Y315S-6	81 84.6 84.2	1.69 2.06 2.75	440	350	300	1210
14SA-10JB (14SA-10E)	600 720 900	166.6 200 250	23 21 18	980	44.2 47.3 53.1	75	Y315S-6	85 87 83	4 4 4.1	425	350	300	1210
14SA-10F	450 547 684	125 152 190	15.6 14.5 12.7	742	22.75 25.1 27.8	37	Y280S-8	84 86 85	5.8 5.8 5.8	440	350	300	1210
350S16	972 1260 1476	270 350 400	20 16 13.4	1480	63.8 63.9 72.8	75	Y280S-4	83 86 74	5.3	290	350	350	895
350S16A	800 967 1167	222.2 268.6 324.2	13.7 11.5 8.6	1480	40.3 38.8 39	55	Y250M-4	74 78 70	5.3	250	350	350	895
350S26	972 1260 1440	270 350 400	32 26 22	1480	99.7 101.5 105	132	Y315M-4	85 88 82	5.3	340	350	300	875
350S26A	843 1088 1264	234.2 302.2 351.1	24.7 20.4 15.7	1480	70.9 72.8 74	90	Y280M-4	80 83 73	5.3	315	350	300	875
350S44	972 1260 1476	270 350 410	50 44 37	1480	164 177.6 189	220	Y355M1-4	81 87 79	5.3	406	350	300	1120
350S44A	876 1131 1350	243.3 314.2 375	42 37 31	1480	125.2 135.8 142.6	160	Y315L1-4	80 84 80	5.3	367	350	300	1120
350S75	972 1260 1440	270 350 400	80 75 65	1480	271 303 319	355	Y4501-4	78 85 80	5.3	493	350	250	1200
350S75A	900 1170 1332	250 325 370	70 65 56	1480	220 247 257	280	Y355L1-4	78 84 79	5.3	470	350	250	1200
350S75B	813 1060 1202	226 294 334	57 53 45.8	1480	168 187 195	220	Y335M1-4	75 82 77	5.3	435	350	250	1200
350S125	850 1260 1660	236 350 461	140 125 100	1480	463 530 624	710	Y5001-4	70 81 72.5	5.3	655	350	200	1420
350S125A	787 1157 1538	219 321 427.2	120 107 86	1480	367 432 515	560	Y4505-4	70 78 70	5.3	620	350	200	1420
350S125B	754 1098 1448	209.4 305 402.2	108 96 77	1480	313 373 419	500	Y4504-4	70 77 72.5	5.3	575	350	200	1420
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
16SA-9	1080 1260 1620	300 350 450	97.6 96 90	1480	400 428 473	630	Y450-4	71.6 77 84	5.2 5.9 7.9	535	400	350	1910
16SA-9A	1080 1260 1620	300 350 450	85.8 85 78	1480	346 370 410	450	Y400-4	73 79 84	5.2 5.9 7.9	510	400	350	1910
16SA-9B	1080 1260 1620	300 350 450	78 76 68	1480	298 318 349	450	Y400-4	77 82 86	5.2 5.9 7.9	480	400	350	1910
16SA-9J (16SA-9C)	900 1080 1260	250 300 350	42 40 38	980	130 140 155.3	185	Y355M2-6	79 84 84	1.79 2.33 2.84	535	400	350	1910
16SA-9JA (16SA-9D)	900 1080 1260	250 300 350	37 35 32	980	112 123 131	160	Y355M1-6	81 84 84	4.6 4.9 5.2	510	400	350	1910
16SA-9JB (16SA-9E)	800 900 1080	222.22 250 300	33 32 30	980	89 95 102.5	110	Y315L1-6	80 83 86	4.6 4.6 4.9	480	400	350	1910
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
20SA-22	1368 1980 2304	380 550 640	26.5 21 17.5	980	122 133.2 137.2	160	Y315M-6	80 85 80	4.4 5.2 5.8	466	500	400	1610
20SA-22A	1260 1800 2088	350 500 580	21 16 12.4	980	90 92.3 88.1	110	Y315L1-6	80 85 80	4.3 4.9 5.4	425	500	400	1610
20SA-22J (20SA-22B)	1080 1450 1800	300 402.7 500	16.3 14 10.7	742	61.5 65 66.8	90	Y315L1-8	78 85 78.5	2.8 4 7.1	458	500	400	1610
20SA-22JA (20SA-22C)	1080 1300 1627	300 361 452	10.3 9.5 6.8	742	37 41 38.6	55	Y315S-8	82 85 78	2.8 3.5 5.6	425	500	400	1610
500S13	1620 2020 2340	450 561.1 650	15 13 10.4	980	83.8 86.2 82.8	110	Y315L1-16	79 83 80	4.5 4.7 5	390	500	500	2173
500S13A	1490 1860 2100	413.9 516.7 583.3	12.8 11 9	980	66.8 68 65.5	75	Y315S-6	77.8 82 78.6	4.5 4.7 5	360	500	500	2173
500S22	1620 2020 2340	450 561.1 650	24.5 22 19.4	980	140.4 144.1 145.4	185	Y355M2-6	77 84 85	5.2	465	500	400	1680
500S22A	1400 1746 2020	388.9 485 561.1	20 17 14	980	103 101 93.8	132	Y315L2-6	74 80 82.1	5.2	427	500	500	1680
500S30	2258 2800 3150	627 778 87.5	33 30 26.5	980	248 260 274	280	Y4002-6	82 86 83	5.0 6.2 7.6	530	500	350	2340
500S35	1620 2020 2340	450 561 650	40 35 28	980	207.6 219 210	250	Y450-6*	85 88 85	4.8	530	500	350	2340
500S35A	1400 1746 2020	389 485 561	31 27 21	980	144 151 138	220	Y355L1-6	82 85 84	4.8	498	500	350	2340
500S40	1788 2020 2314	496.7 561.1 642.8	42.5 40.3 36.4	980	234.8 245.1 251.9	280	Y4002-6	88.2 90.5 91.1	3 3.2 4.1	566	500	350	2400
500S40A	1676 1969 2262	465.6 546.9 628.3	37.9 35 31.2	980	198.7 211 223.6	250	Y3556-6	87.1 89 86	3 3.2 4.1	535	500	350	2400
500S45	2124 2400 2750	590 667 764	47.5 45 40	980	323 338 349	400	Y4005-6	85 87 86	3.4 3.6 4.6	595	500	350	2400
500S59	1620 2020 2340	450 561 650	68 59 47	980	380 391 374	450	Y4506-6	79 83 80	4.5	675	500	350	2747
500S59A	1500 1872 2170	417 520 603	57 49 39	980	315 330 320	400	Y4505-6	74 75 72	4.5	625	500	350	2747
500S59B	1400 1746 2020	389 485 561	46 40 32	980	240 257 248	315	Y4503-6	73 74 71	4.5	583	500	350	2747
500S98	1620 2020 2340	450 561.1 650	114 98 79	980	644.8 678 680.3	800	Y5005-6	78 79.4 74	4	860	500	300	3800
500S98A	1500 1872 2170	416.7 520 602.8	96 83 67	980	509.3 540 542.4	630	Y5003-6	77 78.5 73	4	800	500	300	3800
500S98B	1400 1746 2020	388.9 485 561	86 74 59	98	431.4 452 432.8	560	Y5002-6	76 78 75	4	745	500	300	3800
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
24SA-10	2592 3420 3600	720 950 1000	78 71 69	980	643.9 738.8 760	900	Y5003-6	85.5 89.5 89	5.6 5.9 8.2	725	600	500	4100
24SA-10J (24SA-10A)	2160 2700 2970	600 750 825	43 39 36	742	290.7 322.2 334.6	400	Y4503-8	87 89 87	5.6 5.9 8.2	725	600	500	4100
24SA-10B	2338 3084 3248	649 856.6 902.2	63.5 57.8 56.2	980	472.8 545.4 558.5	630	Y4504-6	85.5 89 89	4.6 7.3 8.2	655	600	500	4100
24SA-18	2700 3240 3600	750 900 1000	35.1 32.6 29.76	980	310.9 330.1 341.2	400	Y4005-6	83.1 87 85.5	4.5 5.15 6.12	550	600	500	3300
24SA-18A	2520 3000 3165	700 833.3 879	25.5 23 19.2	980	206 211 204	250	Y355L2-6	85 89	6 6.4 8.1	490	600	500	3300
24SA-18J (24SA-18B)	2052 2466 2836	570 685 787	20.3 18.9 16.1	742	136.6 145.6 147.4	160	Y355M-B	83.1 87.2 84.4	2.83 3.19 4.03	550	600	500	3300
24SA-18JA (24SA-18C)	1908 2000 2520	530 555.5 700	14.7 13.5 11.2	742	90 86.5 88.3	110	Y315L2-8	84.5 85 87	3.2 3.7 4.4	490	600	500	3300
*24SA-18D	2160 3240 3450	600 900 958	23.2 16 14.2	742	166 166 163	200	Y400-8	82 85 81.6	4.7 5.1 5.5	539	600	500	3300
24SA-18F	1800 3000 3375	500 833 937	33.3 26.6 23.3	980	242.2 263.3 263.7	280	Y4002-6	67.4 82.7 81.2	4.56 3.97 6	510	600	500	3300
600S22	2593 3241 3739	720.3 900.3 1038.6	27.6 23.1 18	980	226.8 231.8 232.1	280	Y450-6*	86 88 79	7	485	600	500	2717
600S22A	2288 2860 3300	635.6 794.4 916.7	21.5 18 14	980	157.5 161 161.2	185	Y355M2-6	85 87 78	7	445	600	500	2717
600S32	2700 3240 3600	750 900 1000	33.5 32 26	980	291.7 317.5 298	400	Y4505-6	85 89 84	6.4	540	600	500	3149
600S32A	2520 3000 3165	700 833.3 879.2	25.5 23 19.2	980	205.8 211 196.9	250	Y450-6*	85 89 84	6.4	490	600	500	3149
600S36	3300 3800 4300	916.7 1055.6 1194.4	40 36 31	980	413.4 423.6 427.3	500	Y5001-6	87 88 85	8.2 8.4 8.8	570	600	500	3500
600S47	2160 3170 3600	600 881 1000	56.5 47 40.5	980	415.4 455.9 461.7	560	Y5002-6	80 88 86	5.5 6.5 8	636	600	400	4364
600S47A	2400 2920 3500	666.7 811.1 972.2	45 42 35	980	352.5 380 402.2	450	Y4506-6	83.5 88 83	5.5 6.5 8	587	600	400	4364
600S75	2592 3060 3600	720 850 1000	78 75 69	980	644.3 694.4 760	900	Y5601-6	87 88 80	5.6 5.6 10.1	765	600	500	4350
600S75A	2338 3084 3248	500 856.7 900	63.5 57.8 56.2	980	467 539.7 552	630	Y5003-6	85.5 90 89	4.6 7.3 8.2	690	600	500	4350
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
28SA-9	3700 4700 4896	1028 1306 1360	99.5 90 87.7	980	1164 1280 1305	1600	Y6301-6	86.1 90 89.6	7.87 9.25 10	840	700	500	6800
28SA-9J	2111 3600 4200	586 1000 1167	60.1 52 43.8	740	432 569 604	630	Y560-8	80 89.6 83	4.4 5.4 8.9	840	700	500	6800
28SA-10	4536 5292 6350	1260 1470 1764	94 90 77	980	1451 1544 1624	1800	Y6302-6	80 84 82	8 10.4 14.8	840	700	500	5800
28SA-10A	4185 4882.5 5859	1162 1356 1627	80 76.6 65.5	980	1169 1227 1275	1400	Y630-6	78 83 82	7.2 9.2 13.2	775	700	500	5800
28SA-10J	3362 3922 4707	933.9 1089 1307	51.6 49.4 42.3	742	590 628 661	710	Y560-8	80 84 82	5.8 6.8 9.2	840	700	500	5800
28SA-10JA	3102 3618 4343	862 1005 1206	43.9 42 36	742	463 498 519	630	Y560-8	80 83 82	5.6 6.1 8	775	700	500	5800
*28SA-10K	2736 3600 4140	760 1000 1150	53 51 47	742	556 617 646	710	Y560-8	71 81 82	4 5 6	848	700	500	5800
700S25	3930 4500 5000	1092 1250 1389	28 25 22	742	343 346 353	400	Y4005-6	87.5 88.5 85	5.0 5.4 6.3	665	700	500	6450
700S40	3040 3800 4340	844.4 1055.6 1205.6	45.2 41.9 37.7	742	443.1 485.3 501	560	Y5006-8	84.5 89.4 89	3.3 3.6 5	778	700	500	6450
700S40A	2837 3800 4583	788.1 1055.6 1273.1	39.6 34.7 27.7	742	368.4 405.6 412.3	500	Y5005-8	83.1 88.6 83.9	3.3 3.6 5	756	700	500	6450
700S90	4000 4700 5500	1111.1 1305.6 1527.8	97 90 77	980	1201 1281 1358	1600	Y6302-6	88 90 85	5.8 7.4 9.5	840	700	500	6000
700S90J	3000 3600 4200	833.3 1000 1166.7	56 52 44	742	532 579 592	630	Y5601-8	86 88 83	3.6 4.6 5.9	840	700	500	6000
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
32SA-10	6300 8280 9900	1750 2300 2750	73.5 67.5 57.5	742	1510 1720 1856	2240	Y710-3-8	83.5 88.5 83.5	5.9 7 8.5	990	800	600	8300
32SA-10B	5940 7920 9540	1650 2200 2650	67.8 62.5 52.5	742	1321 1523 1643	1800	Y710-1-8	83 88.5 83	5.8 6.7 8.5	950	800	600	8300
32SA-10C	5760 7200 8820	1600 2000 2450	59 53.5 46.5	742	1128.6 1213 1370	1600	Y630-8	82 86.5 81.5	5.7 6.3 7.5	885	800	600	8300
32SA-10J	4860 6480 8100	1350 1800 2250	48.3 44.2 35.5	590	780 881 960	1120	Y630-10	82 88.5 81.5	3.7 4.2 5.3	990	800	600	8300
32SA-10JB (32SA-10D)	4680 6300 7740	1300 1750 2150	44 40.5 33	590	684 785 848	1000	Y630-10	82 88.5 82	3.6 4 5	950	800	600	8300
32SA-19	4390 5400 5760	1219 1500 1600	33.3 29 26.3	742	470 473.8 485.3	560	Y5006-8	84.6 90 85	6.3 8.2 10.3	708	800	600	6000
32SA-19A	4170 5000 5470	1158 1388 1519.4	29.3 26 23.7	742	391 393.3 415.3	500	Y5005-8	85 90 85	6.1 7.2 9.3	670	800	600	6000
32SA-19B	3654 4700 5220	1015 1305.5 1450	23.7 20 17	742	275.8 284.5 282	355	Y450-8	85.5 90 85.5	6 6.3 8.2	616	800	600	6000
32SA-19E	4320 5278 6034	1200 1466 1676	36.8 33.8 29.6	742	512.3 545.8 559	630	Y560-8	84.5 89 87	5.9 6.4 9.4	730	800	600	6000
32SA-19J	3456 4320 4615	960 1200 1282	21.6 18.6 17	590	231.1 243.1 254	280	Y450-10	87.8 90 84.1	3.5 5 6.4	708	800	600	6000
32SA-19JA (32SA-19C)	3240 4000 4320	900 1111 1200	19.1 16.5 15.2	590	192.6 199.7 204.3	250	Y450-10	87.5 90 87.5	4 4.5 6.1	668	800	600	6000
32SA-19JB (32SA-19D)	2880 3800 3960	800 1055 1100	15.8 13 11.8	590	146.6 151.1 147.1	200	Y400-10	84.5 89 86.5	3.9 4 4.4	610	800	600	6000
32SA-19F	3726 4705 5407	1035 1307 1502	26.5 23 19	742	323.9 335 341.1	400	Y630-8	83 88 82	6.1 7.4 9.2	630	800	600	6000
32SA-25	4320 5400 6300	1200 1500 1750	25.2 22.3 17.4	742	352 367 364	400	Y4503-8	84 89.3 82	6.1 7.4 9.2	620	800	600	6000
32SA-25J	3240 4140 5040	900 1150 1400	16.6 15 11.5	595	179.7 190 190.2	250	Y4502-10	81.5 89 83	4.0 4.9 6.8	620	800	600	6000
800S19	6084 8600 9396	1690 2390 2610	23.5 18.6 15.4	495	453 496 464	630	YKK630-12	86 88 85	4.9 6.0 6.9	870	800	700	6000
800S22	4320 5500 6840	1200 1527.8 1800	25 22 19	742	358.7 370.2 385.4	450	Y5004-8	82 89 86	7	640	800	600	7580
800S22J	3000 4400 5040	833.3 1222 1400	16 14 12.5	742	163.4 190.6 201.8	250	Y500-10*	80 88 85	5	640	800	600	7580
800S22A	3960 4830 5500	1100 1341.7 1527.8	19 17 15	742	246.9 254.1 261.2	315	Y5001-8	83 88 86	7	570	800	600	7580
800S22JA	2800 3870 4500	777.8 1070 1250	13 11 9.5	590	123.9 133.3 138.6	185	Y355L-10	80 87 84	5	570	800	600	7580
800S24	5250 7000 8400	1458 1944 2333.3	27.5 24 20	742	479 506 532	630	Y5601-8	82 90 86	9	658	800	700	7620
800S24J	4170 5600 6700	1158.3 1555.6 1861.1	17.4 15 12.5	590	244 260 272	315	Y5004-10	81 88 84	6	658	800	700	7620
800S24A	4840 6250 7740	1344.4 1736.1 2150	23.6 21 17.2	742	382 406 429	500	Y5005-8	81.5 88 84.5	9	610	800	700	7620
800S24JA	3850 5000 6150	1069.4 1388.9 1708.3	15 13 11	590	194 203 219	280	Y5003-10	81 87 84	6	610	800	700	7620
800S32	4320 5500 6480	1200 1527.8 1800	35 32 29	742	502.2 538.5 588.2	630	Y5601-8	82 89 87	7	710	800	600	7600
8O0S32A	3500 4950 6000	972 1357 1666.7	30 26 23	742	353 398.3 437	450	Y5004-8	81 88 86	7	645	800	600	7600
800S47	4320 5500 6480	1200 1527.8 1800	51 47 42	742	740.7 782.2 842.2	1000	Y6301-8	81 90 88	6.5	820	800	600	8200
800S47J	3000 4400 5200	833.3 1222 1444	35 30 26	590	357.4 403.9 428.1	450	Y5601-10	80 89 86	4	820	800	600	8200
800S47A	3500 5070 6000	972 1408 1666.7	45 40 36	742	529.5 620.5 684	710	Y5602-8	81 89 86	6.5	760	800	600	8200
800S47JA	2800 4060 4800	777.8 1127.8 1333	30 25 22	590	286 314.1 334.4	355	Y5005-10	80 88 86	4	760	800	600	8200
800S76	5920 7360 8075	1644.4 2044.4 2243	76 72 69	742	1426 1570 1760	1800	Y710-7-8	86 92 89	5.8 6.4 8.5	990	800	600	9000
800S76J	4750 5890 6365	1319.4 1636.1 1768	48 45.5 43.5	590	734 807 857	1000	Y6303-10	84.7 90.5 88	3.6 4.5 5.3	990	800	600	9000
800S76A	4750 6080 6745	1319.4 1688.9 1873.6	61 58 55	742	929 1056 1162	1250	Y6303-8	85 91 87	5.8 6.4 8.5	885	800	600	9000
800S76JA	3895 4980 5510	1081.9 1383.3 1530.6	38.5 36.5 34.8	590	488 553 610	710	Y5605-10	83.7 89.6 85.7	3.6 4.5 5.3	885	800	600	9000
800S76B	4370 5550 6175	1213.9 1541.7 1715.2	55 52.3 49.5	742	777 876 965	1120	Y6302-8	84.3 90.3 86.3	5.8 6.4 8.5	840	800	600	9000
800S76JB	3560 4410 4900	988.9 1225 1361.1	34.7 33 31.3	590	406 448 486	560	Y5603-10	83 88.5 86	3.6 4.5 5.3	840	800	600	9000
800S76JJ	3990 4940 5320	1108.3 1372.2 1477.8	33.7 32 30.7	495	441 490 530	630	Y6302-12	83 88 84	3.2 3.4 4.7	990	800	600	9000
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
S200-95 (8SA-7)	216 280 336	60 77.78 93.5	99 95 87	2980	78.6 90.8 101	132	Y315M-2	74 80 79	4 4.7 6.6	272	200	125	215
S200-95A (8SA-7A)	210 262 314	58.4 72.78 87.2	87 83 74	2980	68.1 76.9 83.3	110	Y315S-2	73 77 76	4 4.5 5.7	255	200	125	215
S200-95B (8SA-7B)	190 247 300	55 68.61 83.4	76 73 63	2980	57 64.6 71.4	75	Y280S-2	72 76 72	4 4.2 5.4	234	200	125	215
S200-63 (BSA-10)	194 280 351	54 77.78 97.5	71 63 52	2980	52 59.3 65.4	75	Y280S-2	72 81 76	2.8 4.1 5.3	235	200	150	235
S200-63A (8SA-10A)	180 259 324	50 71.94 90	58 52 41	2980	40.6 46.5 50.2	55	Y250M-2	70 79 72	2.7 3.8 4.9	217	200	150	235
S200-63B (8SA-10B)	173 239 288	48 66.4 80	48 44 36	2980	32.2 36.6 38.2	45	Y225M-2	70 78 74	2.6 3.5 4.2	200	200	150	235
900S36	6000 7500 9000	1666.7 2083.3 2500	40 36 32	590	769.4 817.5 907.3	1000	Y6303-10	85 90 86.5	5.3 6.2 7.3	980	900	9000	11200
900S36A	5700 6600 7900	1583.3 1833.3 2194.4	34.3 32 27.5	590	622.4 654 687.6	800	Y6301-10	85.6 88 86.1	4 4.5 5.3	905	900	900	11200
900S36*	7080 8140 9330	1966.7 2261.1 2591.7	38 36 31	590	843 897 927	1000	Y6303-10	87 89 85	4.7 5.1 6.3	910	900	900	11200
——END——

ParameterType	Capacity Q		Head H	Speed N	Shaft power Pa	Motor		Eff. η	NPSH r	impolier Dia	Pump diameter		weight
	Capacity Q		Head H	Speed N	Shaft power Pa	power	Type	Eff. η	NPSH r	impolier Dia	Inlet Dia	Outlet Dia	weight
	m³/s	L/s	m	r/min	kW	kW	Type	%	m	mm	mm	mm	kg
1200S22	7920 9612 10800	2200 2670 3000	25.5 22 18	495	644 662 638	800	Y6304-12	85.5 87 83	5.8	955	1200	800	25600
1200S22A	7200 9000 10080	2000 2500 2800	22.5 20.2 17.5	495	534 573 585	710	Y6303-12	83.8 86.5 82.2	5.8	910	1200	800	25600
——END——
